Technical Specifications
| Item | Specification |
|---|---|
| Model | Schneider BMEH586040 |
| Type | Modular Power Supply / Distribution Module |
| Product Category | PLC power accessory |
| Product Family | Modicon BMEX distributed I/O and controller systems |
| Function | Provides 24 V DC power for BMEX I/O modules and distributed systems |
| Input Voltage Range | 100–240 V AC |
| Nominal Output Voltage | 24 V DC |
| Output Current | 5 A |
| Output Power | 120 W |
| Regulation | Regulated DC output |
| Protection Features | Overload protection, short-circuit protection |
| Status Indication | LED indicator for DC output status |
| Mounting Method | DIN rail or panel mount (system base) |
| Connection Method | Screw-type terminals for input and output power |
| Operating Temperature Range | 0 °C to +60 °C |
| Storage Temperature Range | –20 °C to +70 °C |
| Application Environment | Industrial automation and control cabinets |
| Compatibility | BMEX distributed I/O and compatible controller systems |
| Housing Material | Industrial-grade plastic with metal internal components |
| Protection Rating | IP20 |
| Dimensions | Approx. 150 mm × 100 mm × 65 mm |
| Weight | Approximately 0.75 kg |
FAQ
FAQ
Q1: What is the primary purpose of the BMEH586040 module?
It provides 24 V DC power with up to 5 A capacity for BMEX distributed I/O modules and controllers.
Q2: What input voltage range does the BMEH586040 support?
It accepts a wide input range from 100 V AC to 240 V AC.
Q3: What output current and power rating does this module provide?
It delivers 24 V DC at up to 5 A output, providing up to 120 W of power.
Q4: What protection features are included?
It includes overload protection and short-circuit protection to safeguard the module and connected devices.
Q5: How is the BMEH586040 mounted?
It is mounted using DIN rail or panel mount arrangements within industrial control cabinets.
Q6: Does the module provide power status indication?
Yes, it includes LED indicators that display DC output status.
Q7: Can the BMEH586040 be used in harsh industrial environments?
Yes, it is designed for industrial automation environments with standard temperature and humidity conditions.
Q8: What are the physical dimensions and weight of the module?
The module measures approximately 150 mm × 100 mm × 65 mm and weighs about 0.75 kg.
