Technical Specifications
| Item | Specification |
|---|---|
| Model | Schneider BMXCPS4002 |
| Type | Power Supply Module |
| Product Category | PLC I/O power accessory |
| Product Family | Modicon M340 / BMX distributed I/O system |
| Function | Provides DC power to BMX I/O and CPU modules |
| Input Voltage Range | 100–240 V AC |
| Nominal Output Voltage | 24 V DC |
| Output Current | 2 A |
| Output Power | 48 W |
| Regulation | DC regulated output |
| Protection Features | Overload and short-circuit protection |
| Status Indication | Power ON LED indicator |
| Mounting Method | DIN rail mounting |
| Connection Method | Screw terminals for field and internal power distribution |
| Operating Temperature Range | 0 °C to +60 °C |
| Storage Temperature Range | –20 °C to +70 °C |
| Application Environment | Industrial automation and control cabinets |
| Compatibility | Modicon M340 and BMX I/O modules requiring 24 V DC power |
| Housing Material | Industrial-grade plastic |
| Protection Rating | IP20 |
| Dimensions | Approx. 90 mm × 72 mm × 64 mm |
| Weight | Approximately 0.29 kg |
FAQ
FAQ
Q1: What is the main purpose of the BMXCPS4002 power supply module?
It provides regulated 24 V DC power with up to 2 A output to BMX distributed I/O and PLC modules.
Q2: What input voltage range does the BMXCPS4002 support?
It supports a wide input range from 100 V AC to 240 V AC.
Q3: What is the output voltage and current rating of this power supply?
It delivers 24 V DC at up to 2 A output current.
Q4: Does the BMXCPS4002 include protection features?
Yes, it has overload and short-circuit protection to safeguard connected modules.
Q5: How is the BMXCPS4002 mounted?
It is mounted on a standard DIN rail inside an industrial control cabinet.
Q6: Does the module provide status indication?
Yes, it includes an LED indicator that shows when power is on.
Q7: Can the BMXCPS4002 be used in harsh industrial environments?
Yes, it is designed for industrial control cabinets, supporting standard operating temperatures.
Q8: What are the physical dimensions and weight of the BMXCPS4002?
The power supply module measures approximately 90 mm × 72 mm × 64 mm and weighs about 0.29 kg.
Tags
Packing & Delivery
We will use wear-resistant cartons to seal the boxes, and take photos for your confirmation before sealing. We will pack the boxes only after confirmation.
For express delivery, we will use DHL, UPS, TNT, FedEx and EMS.
Please rest assured that we have a deep cooperation with express delivery companies and can ensure that your goods are delivered to you in good condition.
