Technical Specifications
| Parameter | Description |
|---|---|
| Product Name | Schneider Electric BMEXBP1200 |
| Part Number | BMEXBP1200 |
| Product Type | Modicon X80 Ethernet Backplane Rack |
| Manufacturer | Schneider Electric |
| Function | Provides mechanical and electrical backplane platform for M580 / X80 PLC modules (CPU, I/O, power supply, communication modules) |
| Application | Industrial automation / Modicon M580 PAC systems / Modicon X80 architecture |
| System Compatibility | BMXCPS power supply, BMEP / BMX processors, X80 I/O modules |
| Slot Capacity | 12 slots (8 Ethernet/X-bus + 4 X-bus) |
| Backplane Type | Dual Ethernet + X-bus architecture |
| Power Consumption | ~164 mA @ 24 VDC, ~86 mA @ 3.3 VDC |
| Electrical Connection | 1 × XBE expansion connector |
| Protection Class | IP20 |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Humidity | 5–95% RH non-condensing |
| Installation Type | Panel mount / DIN rail / rack mounting |
| Dimensions (W × H × D) | Approx. 503 × 105 × 19 mm |
| Weight | Approx. 1.38 kg |
FAQ
FAQ
Q1: What is Schneider BMEXBP1200 used for?
A1: It is a backplane rack used in Modicon M580 / X80 PLC systems to mechanically and electrically connect CPU, I/O, and communication modules.
Q2: Is BMEXBP1200 a module or a rack?
A2: It is a rack/backplane, not an electronic module.
Q3: How many slots does it have?
A3: It has 12 slots in total, supporting Ethernet/X-bus and X-bus modules.
Q4: What PLC system is it compatible with?
A4: It is used with Schneider Modicon M580 and X80 architecture systems.
Q5: What is its operating temperature range?
A5: It operates between 0°C and +60°C.
Q6: What is its weight?
A6: Approximately 1.38 kg.
Q7: What are its physical dimensions?
A7: Approximately 503 × 105 × 19 mm.
Q8: What is its main function in the system?
A8: It distributes power and communication signals between PLC modules via the backplane bus system.
