Technical Specifications
| Item | Specification |
|---|---|
| Product Name | Schneider Electric BMXSDO0802 |
| Product Type | Safety Discrete Output Module |
| Product Series | Modicon X80 Safety |
| Discrete Output Channels | 8 Outputs |
| Output Type | Solid-State, Non-Isolated |
| Output Logic | Positive Logic |
| Output Voltage | 24 V DC (19–30 V DC Range) |
| Nominal Output Current | 0.5 A per Output |
| Maximum Current per Channel | 0.625 A |
| Maximum Current per Module | 10 A |
| Output Compatibility | IEC 61131-2 Type 3 DC Input |
| Maximum Leakage Current | 0.5 mA at OFF State |
| Maximum Voltage Drop | < 1.2 V at ON State |
| Response Time | 1.2 ms |
| Load Impedance | ≥ 48 Ω |
| Maximum Tungsten Load | 6 W |
| Paralleling of Outputs | Yes, Up to 2 Outputs |
| Insulation Resistance | > 10 MΩ at 500 V DC |
| Power Dissipation | 4.4 W |
| Current Consumption | 264 mA at 3.3 V DC; 15 mA at 24 V DC |
| Protection Features | Reverse Polarity, Overload, Overvoltage, Short-Circuit Protection |
| Overload Protection | Electronic Circuit Breaker and Current Limiter |
| Overvoltage Protection | Transil Diode |
| Short-Circuit Protection | External 2 A Fuse |
| Voltage Detection Threshold | < 14 V DC (Fault), > 18 V DC (OK) |
| Status Indicators | RUN, ERR, I/O, and Channel Diagnostic LEDs |
| Safety Rating | SIL 3, Category 4, PL e |
| MTBF | 383,000 Hours |
| Protection Rating | IP20 |
| Protective Treatment | Conformal Coating |
| Operating Temperature | -25°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Relative Humidity | 5%–95% Non-Condensing |
| Vibration Resistance | 3 gn |
| Shock Resistance | 15 gn |
| Operating Altitude | 0–2000 m (5000 m with Derating) |
| Certifications | CE, UL, CSA, ATEX, IECEx, TÜV |
| Electrical Connection | BMXFTB2000 20-Point Terminal Block |
| Dimensions (W × H × D) | 32 × 100 × 86 mm |
| Weight | 0.12 kg |
| Country of Origin | France |
FAQ
FAQ
Q1: What is the BMXSDO0802 used for?
The BMXSDO0802 is a safety discrete output module designed for Modicon M580 Safety systems. It controls safety-related devices such as contactors, relays, shutdown circuits, and actuators in SIL-rated applications.
Q2: How many outputs does the module provide?
The module provides eight solid-state digital output channels with positive 24 V DC logic.
Q3: What is the output voltage and current rating?
Each output operates at 24 V DC and supports 0.5 A nominal output current, with a maximum channel current of 0.625 A.
Q4: Is the BMXSDO0802 suitable for functional safety systems?
Yes. The module is designed for safety applications and is commonly used in systems requiring SIL 3, Category 4, and Performance Level e (PL e) compliance when properly integrated into a certified safety architecture.
Q5: What protection features are included?
The module includes reverse polarity protection, overload protection, overvoltage protection, short-circuit protection, electronic current limiting, and an external fuse arrangement for enhanced safety.
Q6: What are the dimensions and weight of the BMXSDO0802?
The module measures approximately 32 × 100 × 86 mm and weighs about 0.12 kg, allowing compact installation in Modicon X80 racks.
Q7: How can users monitor the status of the module?
The front panel includes RUN, ERR, I/O, and individual channel diagnostic LEDs, enabling fast troubleshooting and status verification.
Q8: Which industries commonly use the BMXSDO0802?
The module is widely used in oil and gas, chemical processing, power generation, water treatment, transportation, mining, and other industrial sectors where safety-certified output control is required.
