Technical Specifications
| Item | Specification |
|---|---|
| Model | Schneider HMIPSPS752D1X01 |
| Type | Power Supply Module |
| Product Category | PLC Power Accessory |
| Product Family | Modicon M340 / HMIP series |
| Supply Input Voltage | 100–240 V AC |
| Output Voltage | 24 V DC |
| Output Current | 7.5 A |
| Rated Power | 180 W |
| Protection Features | Overload protection, short-circuit protection |
| Status Indication | LED indicators for power status |
| Mounting Method | DIN rail mounting |
| Connection Method | Screw terminals for input and output power |
| Operating Temperature Range | 0 °C to +60 °C |
| Storage Temperature Range | –20 °C to +70 °C |
| Application Environment | Industrial automation and control cabinets |
| Compatibility | Modicon HMIP and M340 systems requiring 24 V DC power |
| Housing Material | Industrial-grade plastic |
| Protection Rating | IP20 |
| Dimensions | Approx. 125 mm × 100 mm × 65 mm |
| Weight | Approximately 0.85 kg |
FAQ
FAQ
Q1: What is the primary purpose of the HMIPSPS752D1X01?
It provides regulated 24 V DC power with up to 7.5 A output for PLC and distributed I/O modules.
Q2: What input voltage range does the HMIPSPS752D1X01 support?
It supports a wide AC input range from 100 V to 240 V.
Q3: What output current and power rating does this module provide?
It delivers 24 V DC at up to 7.5 A, with a total power rating of 180 W.
Q4: Does the power supply include protection features?
Yes, it includes overload and short-circuit protection.
Q5: How is the HMIPSPS752D1X01 mounted?
It is mounted on a standard DIN rail inside an industrial control cabinet.
Q6: Does the unit provide status feedback?
Yes, LED indicators display the power output status.
Q7: Can this power supply be used in harsh industrial environments?
Yes, it is designed for industrial automation applications within standard operating temperature ranges.
Q8: What are the physical dimensions and weight of the HMIPSPS752D1X01?
The module measures approximately 125 mm × 100 mm × 65 mm and weighs about 0.85 kg.
