Technical Specifications
| Item | Specification |
|---|---|
| Model | Schneider 140DD084300 |
| Type | DC Discrete Output Module |
| Product Category | PLC Output Module |
| Product Family | Modicon Quantum automation platform |
| Function | Provides DC discrete output signals for industrial automation control |
| Number of Output Channels | 16 outputs (2 groups of 8) |
| Output Voltage Range | 10–60 V DC |
| Maximum Load Current | 12 A per module; 6 A per group |
| Surge Current | 7.5 A for 50 ms |
| Response Time | ≤ 1 ms ON/OFF |
| Output Logic | Positive logic (sourcing) |
| Isolation Ratings | 2500 Vrms channel-to-bus; 700 Vrms group-to-group |
| Protection Features | Internal fuse protection per group |
| Status Indication | LED indicators for each output channel and status |
| Mounting Method | Rack or DIN rail via compatible Quantum base |
| Housing Material | Industrial-grade plastic and metal contacts |
| Operating Temperature | 0 °C to +60 °C |
| Storage Temperature | –40 °C to +85 °C |
| Protection Rating | IP20 |
| Dimensions (H × W × D) | Approximately 47 mm × 163 mm × 309 mm |
| Weight | Approximately 0.45 kg |
FAQ
FAQ
Q1: What is the primary function of the 140DD084300?
It provides multiple DC discrete output channels to control actuators, indicators, and other field devices in industrial automation systems.
Q2: How many output channels are available on this module?
There are 16 discrete output channels arranged in two groups of 8.
Q3: What voltage range and current ratings does this output module support?
It supports 10–60 V DC output voltage, with up to 12 A total load current per module and 6 A per output group.
Q4: What type of logic does the module use for its outputs?
The outputs use positive logic (sourcing), meaning they source current to the load when active.
Q5: Does the module include protection for outputs?
Yes, it has internal fuse protection for each output group to protect against overcurrent.
Q6: How fast can the outputs respond?
The module has a fast response time of less than 1 millisecond for switching outputs.
Q7: What are the physical dimensions and weight of this module?
The module measures approximately 47 mm × 163 mm × 309 mm and weighs about 0.45 kg.
Q8: In what temperature conditions can this module operate?
It operates reliably from 0 °C up to +60 °C, with storage capability from –40 °C up to +85 °C.
