Technical Specifications
| Parameter | Description |
|---|---|
| Product Model | Schneider Electric LTMR27PFM |
| Manufacturer | Schneider Electric |
| Product Series | TeSys T |
| Product Type | Motor Management Controller |
| Application | Motor monitoring, protection and control |
| Motor Current Range | 1.35–27 A |
| Rated Supply Voltage | 100–240 VAC, 50/60 Hz |
| Supply Voltage Range | 93.5–264 VAC |
| Communication Protocol | PROFIBUS DP |
| Communication Interface | 2-wire RS485 |
| PROFIBUS Address | 1–125 |
| Transmission Rate | 9.6 kbit/s–12 Mbit/s |
| Digital Inputs | 6 |
| Relay Logic Outputs | 3 |
| Fault Signaling | 1 NO + 1 NC |
| Additional Relay Outputs | 3 NO |
| Rated Insulation Voltage | 690 V |
| Short-Circuit Withstand | 100 kA |
| Current Measurement | Phase currents I1, I2, I3, average current and imbalance |
| Earth-Fault Measurement | Yes |
| Motor Temperature Monitoring | Yes |
| Protection Functions | Overload, thermal overload, phase failure, phase imbalance, locked rotor, earth leakage, load fluctuation |
| Power Factor Protection | Supported with LTME expansion module |
| Mounting | DIN rail / mounting plate |
| Protection Rating | IP20 |
| Operating Temperature | -20°C to +60°C |
| Storage Temperature | -40°C to +80°C |
| Dimensions | 91 × 61 × 122.5 mm (W × H × D) |
| Product Weight | Approx. 0.53 kg |
FAQ
FAQ
Q1: What is the Schneider Electric LTMR27PFM used for?
A: It is a TeSys T motor management controller used for monitoring, protection and control of industrial AC motors.
Q2: What motor current range does the LTMR27PFM support?
A: It supports a measurement-current range of 1.35–27 A.
Q3: What power supply does the LTMR27PFM require?
A: It requires 100–240 VAC, 50/60 Hz, with a permitted supply range of approximately 93.5–264 VAC.
Q4: Does the LTMR27PFM support PROFIBUS communication?
A: Yes. It uses PROFIBUS DP over RS485, with addresses from 1 to 125 and transmission rates up to 12 Mbit/s.
Q5: How many digital inputs and outputs does it have?
A: The LTMR27PFM provides 6 logic inputs and 3 relay logic outputs, plus fault-signaling contacts.
Q6: What motor protection functions are available?
A: It supports overload, thermal overload, phase failure, phase imbalance, locked rotor, earth-leakage and load-fluctuation protection.
Q7: What is the difference between LTMR27PFM and LTMR27PBD?
A: Both are 1.35–27 A PROFIBUS DP TeSys T controllers, but the LTMR27PFM uses 100–240 VAC, while the LTMR27PBD uses 24 VDC.
Q8: What are the dimensions and weight of the LTMR27PFM?
A: The controller measures approximately 91 × 61 × 122.5 mm (W × H × D) and weighs approximately 0.53 kg.
