Technical Specifications
| Parameter | Description |
|---|---|
| Product Name | ProSoft PTQ-PDPMV1 |
| Part Number | PTQ-PDPMV1 |
| Product Type | PROFIBUS DP Master Network Interface Module |
| Manufacturer | ProSoft Technology (used in Schneider Quantum systems) |
| Function | Acts as a PROFIBUS DP Master to connect Quantum PLC to PROFIBUS field devices |
| Application | Schneider Modicon Quantum PLC / industrial automation / fieldbus integration |
| Communication Protocol | PROFIBUS DP V0 / DP V1 |
| Data Rate | 9.6 kbps – 12 Mbps |
| Max Slave Devices | Up to 125 slaves (with repeaters) |
| Backplane Type | Quantum PLC backplane (single-slot module) |
| Power Supply | 24 VDC |
| Power Consumption | ~2 W |
| Configuration Software | ProSoft Configuration Builder (PCB) + DTM support |
| Diagnostics | DPV1 acyclic diagnostics, slave status monitoring |
| Operating Temperature | -40°C to +85°C |
| Humidity | 5–95% RH non-condensing |
| Installation Type | Rack-mounted (Quantum chassis, single slot) |
| Dimensions | 88.9 × 22.2 × 38.1 mm |
| Weight | 0.21 kg (210 g) |
FAQ
FAQ
Q1: What is PTQ-PDPMV1 used for?
A1: It is used to connect Schneider Quantum PLC systems to PROFIBUS DP networks as a master interface.
Q2: Is PTQ-PDPMV1 a module or a cable?
A2: It is a communication module, not a cable.
Q3: What system is it compatible with?
A3: It is designed for Schneider Modicon Quantum PLC backplane systems.
Q4: What is its main function?
A4: It manages communication between the PLC and PROFIBUS DP field devices (slaves).
Q5: How many devices can it connect?
A5: Up to 125 PROFIBUS slave devices (with repeaters).
Q6: What is the data speed range?
A6: From 9.6 kbps up to 12 Mbps.
Q7: What is its size?
A7: 88.9 × 22.2 × 38.1 mm.
Q8: What is its weight?
A8: Approximately 0.21 kg (210 g).
