Technical Specifications
| Item | Specification |
|---|---|
| Model | Schneider STBACI1400 |
| Product Type | Standard Analog Input Kit |
| Number of Channels | 4 analog input channels |
| Supported Signal Type | Voltage input |
| Voltage Range | 0–10 V |
| Resolution | 12-bit |
| Kit Components | Analog input module + base module |
| Isolation | Channel-to-bus isolation |
| Operating Voltage | 24 VDC (from STB power supply) |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Relative Humidity | 5–95% non-condensing |
| Mounting Method | DIN rail, Advantys STB island base |
| Dimensions | 70 x 18.4 x 128.3 mm |
| Weight | 0.0998 kg |
FAQ
FAQ
Q1: What components are included in the STBACI1400 kit?
A1: It includes a 4-channel analog input module and the corresponding mounting base.
Q2: What type of analog signal does it support?
A2: It supports voltage input only, within 0–10 V.
Q3: What is the resolution of the module?
A3: The module provides 12-bit resolution.
Q4: Does the module provide electrical isolation?
A4: Yes, it provides channel-to-bus isolation.
Q5: What is the operating temperature range?
A5: The module operates between 0°C and 60°C.
Q6: Is it compatible with the Advantys STB system?
A6: Yes, it is fully compatible with all STB island architectures.
Q7: Does it require an external power supply?
A7: No, it uses the 24 VDC provided by the STB power module.
Q8: Can the module be hot-swapped?
A8: Yes, the kit supports hot-swap during system operation.
