Technical Specifications
| Item | Specification |
|---|---|
| Model | Schneider STBACI1400K |
| Product Type | Standard Analog Input Kit |
| Number of Channels | 4 analog input channels |
| Supported Signal Type | Voltage input |
| Voltage Range | 0–10 V |
| Resolution | 12-bit |
| Kit Components | Analog input module + base module |
| Isolation | Channel-to-bus isolation |
| Operating Voltage | 24 VDC (from STB power supply) |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Relative Humidity | 5–95% non-condensing |
| Mounting Method | DIN rail, Advantys STB island base |
| Dimensions | 70 x 18.4 x 128.3 mm |
| Weight | Package weight: 0.147 kg |
FAQ
FAQ
Q1: What is the difference between STBACI1400K and STBACI1400?
A1: The STBACI1400K is a complete kit version, including the module and the mounting base.
Q2: What type of analog input signal does the kit support?
A2: It supports 0–10 V voltage input signals.
Q3: How many analog channels does the module provide?
A3: The module provides 4 analog input channels.
Q4: What is the resolution of the module?
A4: The resolution is 12-bit.
Q5: Does the module include isolation?
A5: Yes, it features channel-to-bus electrical isolation.
Q6: Is the kit compatible with the Advantys STB system?
A6: Yes, it is fully compatible with all STB islands.
Q7: Is an additional power supply required?
A7: No, it uses the 24 VDC provided by the STB power module.
Q8: Does the kit support hot-swapping?
A8: Yes, it can be hot-swapped without shutting down the system.
