Technical Specifications
| Parameter | Description |
|---|---|
| Product Model | Schneider Electric TM218LDA40DR2HN |
| Manufacturer | Schneider Electric |
| Product Series | Modicon M218 |
| Product Type | Compact Logic Controller / PLC |
| Integrated Digital I/O | 40 points |
| Digital Inputs | 24 inputs |
| Digital Outputs | 16 relay outputs |
| Input Voltage | 24 VDC |
| Input Type | Sink/Source |
| High-Speed Inputs | 4 inputs |
| High-Speed Functions | HSC, PTO, PWM, Frequency Generator |
| Output Type | Relay |
| Relay Outputs | 16 channels |
| Relay Rated Current | 2 A per output |
| Maximum Switching Voltage | 250 VAC / 30 VDC |
| Power Supply | 100–240 VAC |
| Supply Voltage Range | 85–264 VAC |
| Frequency | 50/60 Hz |
| Communication | Serial Link 1 + Serial Link 2 |
| Serial Link 1 | RJ45 |
| Programming Interface | USB |
| Expansion Capability | Up to 4 expansion modules |
| Maximum I/O Capacity | Up to 152 I/O points |
| Programming Software | Schneider Electric Machine Expert |
| Mounting | DIN rail |
| Protection Rating | IP20 |
| Operating Temperature | 0°C to +55°C |
| Storage Temperature | -25°C to +70°C |
| Dimensions | Approx. 190 × 95 × 70 mm (W × H × D) |
| Weight | Approx. 0.75 kg |
FAQ
FAQ
Q1: What is the Schneider Electric TM218LDA40DR2HN used for?
A: It is designed for industrial machine automation applications such as packaging machines, conveyors, assembly equipment, material handling systems, and OEM machinery.
Q2: How many I/O points does the TM218LDA40DR2HN have?
A: It has 40 integrated digital I/O points, including 24 digital inputs and 16 relay outputs.
Q3: What type of outputs does the TM218LDA40DR2HN use?
A: It uses 16 relay outputs, rated at up to 2 A per output.
Q4: What power supply does the TM218LDA40DR2HN require?
A: The PLC operates from a 100–240 VAC power supply, with an allowable range of approximately 85–264 VAC.
Q5: Does the TM218LDA40DR2HN support high-speed counting?
A: Yes. The controller provides fast inputs that can be configured for high-speed counter (HSC) functions and other high-speed control functions.
Q6: What communication interfaces are available?
A: The controller provides USB programming, Serial Link 1 with an RJ45 connector, and Serial Link 2.
Q7: Can the TM218LDA40DR2HN be expanded?
A: Yes. The M218 platform supports expansion modules, allowing additional I/O and functionality to be added to the controller.
Q8: What are the dimensions and weight of the TM218LDA40DR2HN?
A: The controller is approximately 190 × 95 × 70 mm (W × H × D) and weighs approximately 0.75 kg.
