Technical Specifications
| Parameter | Description |
|---|---|
| Product Model | Schneider Electric TM258LD42DT4L |
| Manufacturer | Schneider Electric |
| Product Series | Modicon M258 |
| Product Type | Compact Logic Controller / PLC |
| Supply Voltage | 24 VDC |
| Discrete I/O | 42 points |
| Discrete Inputs | 26 |
| Fast Inputs | 10 |
| Regular Inputs | 12 |
| Discrete Outputs | 16 |
| Fast Outputs | 4 |
| Regular Outputs | 12 |
| Analog Inputs | 4 |
| Analog Input Type | Voltage ±10 V / Current 0–20 mA / 4–20 mA |
| Analog Input Resolution | 12 bits |
| Input Logic | Source / Sink |
| High-Speed Functions | High-speed inputs and outputs |
| Ethernet | Yes |
| Ethernet Port | RJ45 |
| Serial Communication | RS232 / RS485 |
| CANopen | Yes |
| USB | USB Host / programming interface |
| Expansion System | Modicon TM5 |
| Programming Software | EcoStruxure Machine Expert |
| Programming Standard | IEC 61131-3 |
| Mounting | 35 mm DIN rail |
| Protection Rating | IP20 |
| Operating Temperature | 0°C to +50°C vertical installation |
| Operating Temperature | 0°C to +55°C horizontal installation without derating |
| Storage Temperature | -25°C to +70°C |
| Dimensions | 237.5 × 99 × 85 mm (W × H × D) |
| Product Weight | Approx. 0.77 kg |
| Shipping Weight | Approx. 2.00 kg |
FAQ
FAQ
Q1: What is the Schneider Electric TM258LD42DT4L used for?
A: It is a Modicon M258 PLC designed for machine automation applications such as packaging, conveying, hoisting and other industrial control systems.
Q2: How many I/O points does the TM258LD42DT4L have?
A: It has 42 discrete I/O points, consisting of 26 inputs and 16 outputs, plus 4 analog inputs.
Q3: Does the TM258LD42DT4L support analog signals?
A: Yes. It has 4 integrated analog inputs supporting ±10 V, 0–20 mA and 4–20 mA signals with 12-bit resolution.
Q4: What power supply does the TM258LD42DT4L require?
A: The controller operates from a 24 VDC power supply.
Q5: Does the TM258LD42DT4L support high-speed I/O?
A: Yes. It includes 10 fast inputs and 4 fast outputs, with configurable fast-input/fast-output filtering functions.
Q6: What communication interfaces are available?
A: The controller supports Ethernet, RS232/RS485 serial communication, CAN and USB, providing connectivity for machine networks and automation devices.
Q7: Can the TM258LD42DT4L be expanded?
A: Yes. The M258 platform uses the Modicon TM5 modular I/O system, allowing the controller to be expanded for larger automation systems.
Q8: What are the dimensions and weight of the TM258LD42DT4L?
A: The controller measures approximately 237.5 × 99 × 85 mm (W × H × D) and weighs approximately 0.77 kg.
