Technical Specifications
| Item | Specification |
|---|---|
| Model | TM258LF66DT4L |
| Series | Modicon M258 |
| Digital I/O Points | 66 points |
| Analog Inputs | 4 channels |
| Digital Outputs | 24 outputs + 4 fast outputs |
| Input Voltage | 24 V DC (“1” ≥ 15 V, “0” ≤ 5 V) |
| Output Voltage | 24 V DC (source type) |
| Power Supply | 24 V DC, range 20.4–28.8 V DC |
| Memory | 128 MB Flash + 64 MB RAM |
| Isolation | 500 Vrms between channels and logic |
| Communication Interfaces | Ethernet, CANopen, USB, Serial (RS‑232/RS‑485) |
| CPU Execution Speed | Approx. 22 ns per boolean instruction |
| Mounting | DIN rail |
| Protection Rating | IP20 |
| Dimensions | 262.5 x 99 x 85 mm |
| Weight | 0.8 kg |
FAQ
FAQ
Q1: How many digital I/O points does TM258LF66DT4L support?
A1: 66 digital I/O points in total.
Q2: What are the analog input and digital output capabilities?
A2: 4 analog input channels, 24 standard outputs, and 4 fast outputs.
Q3: What are the input/output logic types and voltage?
A3: Inputs use a mix of Sink/Source logic at 24 V DC; outputs are Source type at 24 V DC.
Q4: What power supply is required?
A4: 24 V DC, range 20.4–28.8 V DC.
Q5: What about memory and CPU performance?
A5: 128 MB Flash + 64 MB RAM; CPU executes boolean instructions in approx. 22 ns each.
Q6: What communication interfaces are available?
A6: Ethernet, CANopen, USB programming port, and Serial (RS‑232/RS‑485).
Q7: What are the dimensions and weight?
A7: 262.5 x 99 x 85 mm; weight 0.8 kg.
Q8: What is the isolation and protection rating?
A8: 500 Vrms isolation between channels and logic; protection rating IP20.
