Technical Specifications
| Item | Specification |
|---|---|
| Model | Schneider TM2ALM3LT |
| Product Type | Analog Input/Output Module |
| Function | Acquisition and transmission of analog signals to/from control system |
| Input Signal Type | 0–10 VDC, 4–20 mA |
| Output Signal Type | 0–10 VDC, 4–20 mA |
| Number of Input Channels | 3 |
| Number of Output Channels | 3 |
| Input Impedance | 250 Ω (current), 10 kΩ (voltage) |
| Output Load | Max 500 Ω (current), Min 2 kΩ (voltage) |
| Resolution | 12-bit |
| Accuracy | ±0.2% full scale |
| Isolation | Galvanic isolation between input and output channels |
| Response Time | < 10 ms |
| Communication Interface | TM2 bus |
| Mounting Type | DIN rail |
| Operating Temperature | -20°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Operating Humidity | 5–95% RH (non-condensing) |
| Power Consumption | < 2 W |
| Dimensions (L × W × H) | 23.5 × 70 × 90 mm |
| Weight | 0.085 kg |
FAQ
FAQ
Q1: What types of analog signals can the module handle?
A1: It supports both voltage (0–10 VDC) and current (4–20 mA) signals for input and output.
Q2: How many input and output channels are available?
A2: The module provides 3 analog input channels and 3 analog output channels.
Q3: Is the module isolated?
A3: Yes, galvanic isolation separates input and output channels to prevent interference.
Q4: What is the response time of the module?
A4: The typical response time is under 10 ms, ensuring timely signal transmission.
Q5: What is the measurement accuracy?
A5: The module provides ±0.2% full-scale accuracy with 12-bit resolution.
Q6: What are the impedance requirements for input and output?
A6: Input impedance is 250 Ω for current signals and 10 kΩ for voltage; output can drive loads up to 500 Ω (current) and minimum 2 kΩ (voltage).
Q7: How is the module mounted?
A7: It is designed for standard DIN rail mounting in control panels.
Q8: Does the module require configuration or software?
A8: No onboard configuration is needed; all settings and signal mapping are handled via the TM2 bus and control system.
