Technical Specifications
| Item | Specification |
|---|---|
| Model | Schneider TM2DDO8TT |
| Product Type | Discrete Output Module |
| Output Technology | Transistor outputs |
| Number of Output Channels | 8 |
| Output Type | Sinking (NPN) and sourcing (PNP), configurable |
| Rated Output Voltage | 24 V DC |
| Maximum Output Current | 0.5 A per channel |
| Maximum Inrush Current | 2 A (short duration) |
| Total Output Current | 4 A maximum |
| Output Circuit Protection | Short-circuit and overload protection |
| Output Isolation | Electrical isolation between outputs and internal logic |
| Switching Speed | < 0.5 ms |
| Leakage Current | < 0.1 mA |
| Status Indication | LED indicator per channel |
| External Power Requirement | 24 V DC field supply |
| Communication Interface | TM2 internal bus |
| Wiring Method | Screw terminals |
| Mounting | DIN rail |
| Operating Temperature | -20°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Ambient Humidity | 5–95% RH, non-condensing |
| Power Consumption | < 4 W |
| Dimensions (L × W × H) | 84.6 × 90 × 27.3 mm |
| Weight | 0.085 kg |
FAQ
FAQ
Q1: What is the main purpose of the TM2DDO8TT module?
A1: It provides digital output control for field devices such as relays, solenoids, and indicators.
Q2: Does the module support both NPN and PNP wiring?
A2: Yes, the output mode can be configured based on wiring requirements.
Q3: Can this module handle inductive loads?
A3: Yes, internal suppression protects the outputs when driving inductive devices.
Q4: What happens if an output is shorted?
A4: The module detects the fault and shuts down the affected channel to prevent hardware damage.
Q5: How can I tell if an output is active?
A5: Each channel is equipped with a status LED for real-time monitoring.
Q6: Is external power required for output operation?
A6: Yes, a 24 V DC field power source must be connected.
Q7: Can multiple outputs switch at the same time without delay?
A7: Yes, the module supports simultaneous switching across all channels.
Q8: How are output settings managed in the control system?
A8: Configuration is performed through the PLC software via the system bus interface.
