Technical Specifications
| Parameter | Description |
|---|---|
| Product or Component Type | Ethernet TCP/IP Module |
| Module Format | Standard |
| Physical Interface | RJ45 – 10BASE-T/100BASE-TX, 1 twisted pair |
| Transmission Rate | 10/100 Mbit/s |
| Communication Protocol | Modbus TCP, Uni-Telway |
| Communication Services | Modbus TCP messaging, SMTP email notification, SNMP agent, SOAP XML Web (client/server), Uni-TE messaging |
| Maximum Connections | 64 |
| Web Server | Transparent Ready Class D10 |
| Web Features | FactoryCast HMI active, Data Editor (via PC terminal), Rack Viewer, FactoryCast configurable |
| User Web Page Size | 8 MB |
| Software Compatibility | PL7 Pro, Unity Pro |
| Power Supply | Via the rack power supply |
| Current Consumption | 360 mA, 5 V DC |
| Operating Temperature | 0 to 60 °C (32 to 140 °F) |
| Relative Humidity | 10–95 % up to 60 °C, non-condensing |
| IP Degree of Protection | IP20 |
| Standards Compliance | CSA 1010-1, UL 508, EN 61131-2 |
| Explosion Proof Approval | FM Class 1 Division 2 Groups A, B, C, D |
| Marking | CE |
| Dimensions | 260 × 180 × 60 mm |
| Weight | 0.44 kg |
FAQ
FAQ
Q1: What communication protocols are supported by the module?
A1: The module supports Modbus TCP and Uni-Telway protocols.
Q2: How many network connections can the TSXWMY100 handle simultaneously?
A2: It can handle up to 64 concurrent connections.
Q3: Does this module include web server functionality?
A3: Yes, it features Transparent Ready Class D10 with FactoryCast HMI active.
Q4: How is the TSXWMY100 powered?
A4: It is powered through the rack’s power supply, with no external power needed.
Q5: Which software platforms is the module compatible with?
A5: It is fully compatible with PL7 Pro and Unity Pro.
Q6: Does the module provide any protection rating?
A6: Yes, it has an IP20 protection rating suitable for control cabinet environments.
Q7: Can the module send email alerts?
A7: Yes, it supports SMTP email notification for alarms and events.
Q8: What is the operational temperature range of TSXWMY100?
A8: It operates within a range of 0 to 60 degrees Celsius.
