Technical Specifications
| Parameter | Specification |
|---|---|
| Model | 8290-180 |
| Manufacturer | Woodward |
| Product Type | Generator Load Sensor |
| Function | Measures and monitors generator load signals for precise control and protection |
| Input Signal | 0–5 A AC or 0–10 V AC (depending on configuration) |
| Output Signal | 0–5 V DC or 4–20 mA DC proportional to load |
| Measurement Accuracy | ±0.5% of full scale |
| Frequency Range | 40–70 Hz |
| Power Supply Voltage | 18–32 V DC |
| Power Consumption | < 5 W |
| Response Time | < 100 ms |
| Isolation Voltage | 1500 V RMS (input to output) |
| Operating Temperature | -40°C to +70°C |
| Storage Temperature | -55°C to +85°C |
| Humidity Range | Up to 95% RH, non-condensing |
| Mounting Type | Panel or chassis-mounted |
| Protection Class | IP20 |
| Compliance | CE, UL, and CSA certified |
| Application | Generator control systems, load sharing, power management, and synchronization systems |
| Dimensions | 200 x 150 x 80 mm |
| Weight | 1.8 kg |
FAQ
FAQ
Q1: What is the primary function of the Woodward 8290-180 Generator Load Sensor?
It detects and converts generator current or voltage load signals into a proportional DC output for control and monitoring systems.
Q2: What type of input signals does the 8290-180 support?
It can accept either 0–5 A AC or 0–10 V AC input signals depending on the installation configuration.
Q3: What is the output signal range of this load sensor?
The module provides a DC output of either 0–5 V or 4–20 mA, proportional to the generator load.
Q4: How accurate is the Woodward 8290-180?
It offers a high measurement accuracy of ±0.5% of full-scale output, ensuring precise generator load monitoring.
Q5: What power supply voltage is required for the 8290-180?
The sensor operates with a DC power supply between 18 V and 32 V.
Q6: How fast does the sensor respond to load changes?
It features a response time of less than 100 milliseconds, enabling real-time control performance.
Q7: Does the 8290-180 include electrical isolation?
Yes, it provides 1500 V RMS isolation between input and output for system protection and noise immunity.
Q8: What environments can this sensor operate in?
It is designed for industrial environments with temperatures from -40°C to +70°C and up to 95% relative humidity.
