Technical Specifications
| Parameter | Description |
|---|---|
| Product Name | Digital Speed Control |
| Model Number | 9905-792 |
| Brand | Woodward |
| Product Type | Electronic Speed Control Unit |
| Function | Provides precise digital control of engine or turbine speed |
| Input Signal | Magnetic pickup or frequency input (MPU) |
| Output Signal | Pulse-width modulated signal to actuator |
| Speed Range | 1 Hz to 10 kHz input frequency range |
| Power Supply | 18–32 VDC nominal |
| Power Consumption | 20 W typical |
| Control Mode | Isolated PID control with programmable gain and dynamics |
| Communication Interface | RS-232 serial port for setup and monitoring |
| Adjustment Parameters | Speed setpoint, gain, stability, and droop settings |
| Accuracy | ±0.1% of set speed |
| Response Time | <50 ms typical |
| Operating Temperature | -40°C to +85°C |
| Storage Temperature | -55°C to +105°C |
| Humidity | Up to 95% non-condensing |
| Vibration Resistance | 5 g, 10–500 Hz |
| Shock Resistance | 20 g, 11 ms |
| Protection Features | Reverse polarity, surge, and over-temperature protection |
| Mounting Type | Panel mount |
| Enclosure Rating | IP65 (sealed front panel) |
| Dimensions | 215.9 × 157.48 × 78.74 mm |
| Weight | 1.9 kg |
FAQ
FAQ
Q1: What is the primary function of the Woodward 9905-792 Digital Speed Control?
A1: It provides precise electronic control of engine or turbine speed using digital processing for stable and accurate operation.
Q2: What type of sensors are compatible with this control module?
A2: It is designed to work with magnetic pickup (MPU) sensors or frequency-based speed sensors.
Q3: How is the 9905-792 configured or tuned?
A3: Configuration is performed through a PC connection via the RS-232 interface using Woodward’s setup software.
Q4: What protection mechanisms are integrated in the module?
A4: The unit includes reverse polarity, surge suppression, and over-temperature protection for system safety and reliability.
Q5: Can the speed control unit be used in harsh environments?
A5: Yes, it is designed to operate in extreme temperature ranges, high vibration, and high humidity environments.
Q6: What type of actuators does this controller support?
A6: It supports proportional actuators driven by PWM output for precise engine speed regulation.
Q7: How is the control accuracy maintained under varying load conditions?
A7: The built-in PID algorithm automatically compensates for load fluctuations to maintain steady engine speed.
Q8: In what applications is the 9905-792 Digital Speed Control typically used?
A8: It is commonly used in diesel and gas engines, generator sets, marine propulsion systems, and industrial turbines requiring reliable speed regulation.
