Technical Specifications
| Parameter | Description |
|---|---|
| Product Name | LinkNet 6 Channel Input Module |
| Model Number | 9905-970 |
| Brand | Woodward |
| Product Type | Digital Input Module |
| Function | Provides six isolated digital input channels for monitoring external signals in industrial control systems |
| Number of Channels | 6 isolated digital inputs |
| Input Signal Type | Dry contact or TTL/logic level compatible |
| Input Voltage Range | 18–32 VDC (nominal 24 VDC) |
| Input Current | 5 mA typical per channel |
| Isolation Voltage | 500 VDC channel-to-channel and channel-to-bus |
| Input Response Time | <5 ms |
| Logic “1” Threshold | >15 VDC |
| Logic “0” Threshold | <5 VDC |
| Communication Interface | LinkNet RS-485 or CANopen |
| Power Supply | 18–32 VDC |
| Power Consumption | 8 W typical |
| Diagnostic Features | Channel status, short circuit detection, communication failure indication |
| LED Indicators | Power, network communication, and channel activity LEDs |
| Configuration | Software configurable via LinkNet setup utility |
| Mounting Type | DIN rail or panel mounting |
| Operating Temperature | -40°C to +70°C |
| Storage Temperature | -55°C to +105°C |
| Humidity | 5% to 95% non-condensing |
| Enclosure Rating | IP20 |
| Dimensions | 355.6 x 279.4 x 101.6 mm |
| Weight | 0.907 kg |
FAQ
FAQ
Q1: What is the primary purpose of the Woodward 9905-970 module?
A1: The 9905-970 module is designed to collect and process digital input signals from field devices, enabling real-time monitoring and control in LinkNet-based automation systems.
Q2: What types of signals can the 9905-970 accept?
A2: It supports dry contact and TTL-level digital signals, making it compatible with a variety of switches, sensors, and relays used in industrial control systems.
Q3: How does the module ensure electrical isolation?
A3: Each input channel is optically isolated from others and from the communication bus, preventing interference and protecting sensitive control circuits from voltage transients.
Q4: What communication interface is used for data exchange?
A4: The module utilizes the LinkNet network protocol over RS-485 or CANopen interfaces, providing reliable and synchronized communication with other system components.
Q5: How are diagnostics and system monitoring handled?
A5: The 9905-970 features built-in diagnostic indicators and software monitoring tools that report open circuits, short circuits, and communication errors.
Q6: How can users configure the input parameters?
A6: Configuration is done via the LinkNet setup utility, allowing users to define input logic, filter times, and network settings easily through software.
Q7: What are the main application areas for the 9905-970?
A7: It is commonly used in turbine control, power generation systems, and process automation where accurate digital input monitoring is required.
Q8: Does the module include any visual indicators for operation?
A8: Yes, LED indicators on the front panel display power status, communication activity, and the operational state of each digital input channel for quick system diagnostics.
