Yokogawa AAI135-H03 Analog Input Module

Frequently Asked Questions (FAQ)

Q1: What is the input signal range for the AAI135-H03 module?
A1: The input signal range for the AAI135-H03 module is 4 to 20 mA.

Q2: How many channels does the AAI135-H03 module support?
A2: The module supports 8 isolated input channels.

Q3: Does the AAI135-H03 module support HART communication?
A3: Yes, the module supports HART communication, allowing for additional data and diagnostics.

Q4: What is the accuracy of the AAI135-H03 module?
A4: The accuracy of the module is ±16 µA.

Q5: What is the allowable input current for the module?
A5: The allowable input current is 25 mA.

Q6: What is the withstanding voltage for the module?
A6: The withstanding voltage is 500 VAC for 1 minute, both between input and system and between input channels.

Q7: What is the operating temperature range for the AAI135-H03 module?
A7: The module operates within a temperature range of -20 to 70°C.

Q8: What is the maximum current consumption for the module?
A8: The maximum current consumption is 360 mA at 5 V DC and 450 mA at 24 V DC.

Q9: How is the AAI135-H03 module connected to external devices?
A9: The module can be connected using pressure clamp terminals, MIL connectors, or dedicated cables (KS1).

Q10: What are the dimensions and weight of the AAI135-H03 module?
A10: The dimensions are 107.5×32.8×130 mm, and the weight is 0.3 kg.

AAI135-H03 Analog Input Module field control systems Yokogawa
