Technical Specifications
| Item | Specification |
|---|---|
| Module Type | Analog Input Module |
| Model Number | AAI143-S03 S1 |
| Number of Channels | 16 channels |
| Input Type | 4–20 mA DC (2-wire transmitter supported) |
| Resolution | 16 bits |
| Accuracy | ±0.1% of span |
| Input Impedance | 250 Ω (internal resistance) |
| Isolation | Channel-to-channel and channel-to-ground |
| Power Supply | Supplied via base unit (FIO system) |
| Diagnostics | Disconnection detection, burnout detection |
| Mounting Type | DIN rail |
| Hot Swap | Supported |
| Dimensions | 107.5 × 32.8 × 130 mm |
| Weight | 0.3 kg |
| Operating Temperature | 0 to 60 °C |
| Storage Temperature | -20 to +70 °C |
| Relative Humidity | 5% to 95%, non-condensing |
FAQ
FAQ
Q1: How many analog input channels does the AAI143-S03 S1 module have?
A1: It has 16 analog input channels.
Q2: What type of signal does this module accept?
A2: It accepts 4–20 mA DC current signals.
Q3: Does the AAI143-S03 S1 support 2-wire transmitters?
A3: Yes, it supports 2-wire transmitter connections.
Q4: What is the resolution of the module’s input?
A4: The input resolution is 16 bits.
Q5: Is channel-to-channel isolation provided?
A5: Yes, each channel is isolated from the others and from ground.
Q6: How is power supplied to the module?
A6: Power is supplied through the base unit in the FIO system.
Q7: Does this module support hot-swapping?
A7: Yes, it supports hot swap without shutting down the system.
Q8: What diagnostic functions are included?
A8: The module supports disconnection detection and burnout detection.
