Technical Specifications
| Parameter | Description |
|---|---|
| Model Number | AAI143-S50/K4A00 |
| Type | Analog Input Module |
| Number of Channels | 16 channels |
| Input Type | Current input (4–20 mA) |
| Resolution | 16-bit |
| Accuracy | ±0.1% of full scale |
| Power Supply | 24 VDC (supplied via system) |
| Isolation | Channel-to-system isolation only |
| Operating Temp. | 0 to 55°C |
| Storage Temp. | -20 to 70°C |
| Relative Humidity | 5% to 95%, non-condensing |
| Mounting Method | Plug-in type on baseboard |
| Dimensions | 107.5 × 32.8 × 130 mm |
| Weight | 0.3 kg |
FAQ
FAQ
Q1: What type of input signal does the AAI143-S50/K4A00 support?
A1: It supports standard 4–20 mA current input signals.
Q2: Are the channels on the module isolated from each other?
A2: The channels are not isolated from each other, but are isolated from the system.
Q3: What is the resolution of the module?
A3: The module offers 16-bit resolution.
Q4: What are the environmental conditions for installation?
A4: Suitable for industrial environments between 0–55°C and 5%–95% non-condensing humidity.
Q5: Is hot-swapping supported?
A5: Hot-swapping is not supported; power must be off during insertion or removal.
Q6: Does this module support HART communication?
A6: No, HART protocol is not supported by this model.
Q7: Is an external power supply needed for operation?
A7: No external power supply is needed; it is powered by the system.
Q8: What are the dimensions and weight of the module?
A8: Dimensions are 107.5 × 32.8 × 130 mm, and weight is 0.3 kg.
