Technical Specifications
| Parameter | Specification |
|---|---|
| Model | AAI543-H50/A4S10 |
| Output Channels | 16 isolated output channels |
| Output Signal | 4 to 20 mA |
| Withstanding Voltage | 1500 V AC between output and system (for 1 minute) |
| Allowable Load Resistance | 0 to 750 Ω |
| Circuit-open Detection | Less than 0.65 mA |
| Accuracy | ±48 µA |
| Data Update Period | 10 ms |
| Temperature Drift | ±16 µA/10°C |
| Maximum Current Consumption | 230 mA (5 V DC), 540 mA (24 V DC) |
| External Connection | Pressure clamp terminal, MIL connector cable, KS1 dedicated cable |
| HART Communication | Available (requires compatible ER bus and firmware EB401 Rev.2 or later) |
| Dimensions | 107.5 × 32.8 × 130 mm |
| Weight | 0.4 kg |
FAQ
FAQ
Q1: What is the output signal range of the AAI543-H50/A4S10 module?
A1: The module provides a standard 4 to 20 mA current output.
Q2: How many output channels does this module have?
A2: It features 16 isolated output channels.
Q3: Is the module compatible with HART communication?
A3: Yes, HART communication is supported when installed in a compatible ER bus node unit with the proper firmware.
Q4: What is the maximum allowable load resistance for each channel?
A4: Each channel supports 0 to 750 Ω load resistance.
Q5: What is the typical data update period of the module?
A5: The data update period is 10 milliseconds.
Q6: How is open circuit detection managed in this module?
A6: Open circuit detection is triggered when the current drops below 0.65 mA.
Q7: Can this module be used in dual-redundant configurations?
A7: Yes, the AAI543 supports dual-redundant configurations with standard or fast switch-over models.
Q8: What is the physical size and weight of the module?
A8: The dimensions are 107.5 × 32.8 × 130 mm, and it weighs 0.4 kg.
