Technical Specifications
| Parameter | Specification |
|---|---|
| Model | AAT141-S03 |
| Product Type | TC/mV Input Module |
| Input Type | Thermocouple (TC), Millivolt (mV) |
| Channels | 4 channels |
| Resolution | 16-bit |
| Accuracy | ±0.1% full scale |
| Response Time | ≤200 ms (typical) |
| Operating Temperature | 0°C to 55°C |
| Supply Voltage | 24 VDC |
| Interface Type | Module terminal interface |
| Communication Protocol | Compatible with YOKOGAWA CENTUM VP system |
| Dimensions | 107.5 × 32.8 × 130 mm |
| Weight | 0.2 kg |
FAQ
FAQ
Q1: What applications is the AAT141-S03 module suitable for?
A: Mainly used in industrial process control systems for acquiring thermocouple or millivolt signals to achieve precise temperature monitoring.
Q2: What input types does it support?
A: Supports thermocouple (TC) and millivolt (mV) signals.
Q3: How many channels does the module support?
A: Standard module provides 4 input channels.
Q4: What is the accuracy?
A: Accuracy is ±0.1% full scale, suitable for most industrial processes.
Q5: What is the operating temperature range?
A: Can operate stably from 0°C to 55°C.
Q6: How is the module installed?
A: Installed via the CENTUM VP system module slot and connected to signal lines via terminals.
Q7: What is the power requirement?
A: Requires 24 VDC power supply.
Q8: What are the dimensions and weight of the module?
A: Dimensions are 107.5 × 32.8 × 130 mm, weight approximately 0.2 kg.
