Technical Specifications
| Item | Specification |
|---|---|
| Module Type | Contact Input Module |
| Model | ADM11T-S2 |
| Number of Channels | 16 channels |
| Input Type | Dry contact or voltage contact input |
| Input Voltage | 24 V DC nominal |
| Input Current | 2–5 mA per channel |
| Input Delay Time | Approx. 10 ms |
| Isolation | Optical isolation between field and system |
| Power Supply Voltage | 24 V DC (±10%) |
| Diagnostics | Channel and communication error detection |
| Interface | Internal bus connection |
| Dimensions | 125 x 130 x 248 mm |
| Weight | 0.14 kg |
| Operating Temperature | 0 to 55°C |
| Storage Temperature | -25 to 70°C |
| Mounting | Mounted on baseplate or card holder |
FAQ
FAQ
Q1: What is the function of the ADM11T-S2 module?
The ADM11T-S2 module is designed to receive contact input signals from field devices such as switches and relays, converting them into logic signals for system processing.
Q2: How many input channels does this module provide?
It provides 16 independent contact input channels.
Q3: What type of input signals are supported?
It supports both dry contact and voltage contact input types.
Q4: What is the nominal input voltage?
The nominal input voltage is 24 V DC.
Q5: Is the module optically isolated?
Yes, optical isolation is provided between the field side and the system side to prevent interference.
Q6: Does the module support diagnostics?
Yes, it includes functions for detecting channel and communication errors.
Q7: What are the dimensions and weight of the module?
The module measures 125 x 130 x 248 mm and weighs approximately 0.14 kg.
Q8: What is the operating temperature range?
The operating temperature range is from 0 to 55°C.
