Technical Specifications
| Parameter | Specification |
|---|---|
| Model | ADV151-E10 |
| Number of Input Channels | 32 |
| Rated Input Voltage | 24 V DC (sink/source) |
| Input ON Voltage | 18 to 26.4 V DC |
| Input OFF Voltage | ≤ 5.0 V DC |
| Input Current (at rated voltage) | 4.1 mA ±20% / channel |
| Maximum Allowable Input Voltage | 30.0 V DC |
| Withstanding Voltage | Between input signal & system: 2 kV AC, 1 min; Between commons: 500 V AC, 1 min (common every 16-channel) |
| Functions | Status input detection, Pushbutton input counting, SOE capture |
| Input Response Time | ≤ 8 ms (status input) |
| Minimum ON Detection Time | 20 ms (pushbutton input) |
| Maximum ON/OFF Cycle | 25 Hz (pushbutton input) |
| Maximum Current Consumption | 500 mA (5 V DC) |
| External Connection | Pressure clamp terminal, dedicated cable (AKB331), MIL connector cable |
| Dimensions | 107.5 × 130 × 32.8 mm |
| Weight | 0.3 kg |
FAQ
FAQ
Q1: How many input channels does the ADV151-E10 support?
A1: It supports 32 input channels.
Q2: What is the rated input voltage?
A2: The rated input voltage is 24 V DC, supporting both sink and source modes.
Q3: What is the input response time?
A3: The response time for status input is no more than 8 ms.
Q4: Does this module support SOE event capture?
A4: Yes, the ADV151-E10 supports Sequence of Events (SOE) capture.
Q5: What is the maximum allowable input voltage?
A5: The maximum allowable input voltage is 30.0 V DC.
Q6: What is the minimum ON detection time?
A6: The minimum ON detection time for pushbutton input is 20 ms.
Q7: What are the external connection options?
A7: It can be connected via pressure clamp terminal, dedicated cable (AKB331), or MIL connector cable.
Q8: What are the dimensions and weight of the module?
A8: The dimensions are 107.5 × 130 × 32.8 mm, and the weight is approximately 0.3 kg.
