Technical Specifications
| Parameter | Specification |
|---|---|
| Model | ADV151-E63/D5A00 |
| Type | Digital Input Module |
| Number of Input Channels | 32 channels |
| Rated Input Voltage | 24 V DC (sink/source) |
| Input ON Voltage | 18 to 26.4 V DC |
| Input OFF Voltage | 5.0 V DC or less |
| Input Current (at Rated Voltage) | 4.1 mA ±20% / channel |
| Maximum Allowable Input Voltage | 30.0 V DC |
| Withstanding Voltage | Between input signal and system: 2 kV AC, 1 minute; Between commons: 500 V AC, 1 minute (common every 16 channels) |
| Functions | Status input detection, Pushbutton edge counting, SOE (Sequence of Events) data capture |
| Input Response Time | 8 ms or less (status input) |
| Minimum ON Detection Time | 20 ms (pushbutton input) |
| Maximum ON/OFF Cycle | 25 Hz (pushbutton input) |
| Maximum Current Consumption | 500 mA (5 V DC) |
| External Connection | Pressure clamp terminal, Dedicated cable (AKB331), MIL connector cable |
| Dimensions | 107.5 × 130 × 32.8 mm |
| Weight | 0.3 kg |
FAQ
FAQ
Q1: What is the input voltage range for the ADV151-E63/D5A00?
A1: The rated input voltage is 24 V DC, with an ON voltage range of 18 to 26.4 V DC.
Q2: How many input channels does this module support?
A2: It supports 32 independent digital input channels.
Q3: Does the module support SOE (Sequence of Events) capture?
A3: Yes, it supports SOE data capture for precise event logging.
Q4: What is the maximum allowable input voltage?
A4: The maximum allowable input voltage is 30.0 V DC.
Q5: What is the minimum ON detection time for pushbutton input?
A5: The minimum ON detection time is 20 ms for pushbutton input.
Q6: What is the maximum ON/OFF cycle for pushbutton input?
A6: The maximum ON/OFF cycle is 25 Hz.
Q7: How is the module connected externally?
A7: It can be connected via pressure clamp terminal, dedicated cable (AKB331), or MIL connector cable.
Q8: What are the dimensions and weight of the ADV151-E63/D5A00?
A8: The dimensions are 107.5 × 130 × 32.8 mm, and it weighs approximately 0.3 kg.
