Technical Specifications
| Parameter | Specification |
|---|---|
| Model | ADV157 |
| Type | Digital Input Module |
| Number of Input Channels | 32 channels |
| Rated Input Voltage | 24 V DC (sink/source type) |
| Input ON Voltage Range | 18 to 26.4 V DC |
| Input OFF Voltage | 5.0 V DC or less |
| Input Current | 4.1 mA ±20% per channel |
| Maximum Allowable Input Voltage | 30 V DC |
| Withstanding Voltage | 2 kV AC (Input-System); 500 V AC (Between Commons) |
| Input Response Time | ≤ 8 ms (status input) |
| Pushbutton Input Function | Not supported |
| External Connections | Pressure clamp terminal only |
| Max. Current Consumption | 350 mA (5 V DC) |
| Dimensions (W × H × D) | 130.9 × 130 × 32.8 mm |
| Weight | 0.4 kg |
FAQ
FAQ – Frequently Asked Questions
Q1: What type of signals does the ADV157 support?
A1: It supports 32 channels of 24 V DC ON/OFF input signals, compatible with both sink and source types.
Q2: What is the input response time of the ADV157 module?
A2: The response time for status input is 8 milliseconds or less.
Q3: Does this module support pushbutton input functionality?
A3: No, pushbutton edge detection is not supported. Only standard ON/OFF state detection is available.
Q4: What is the maximum allowable input voltage?
A4: The module can tolerate up to 30 V DC input.
Q5: What types of connection terminals are supported?
A5: Only pressure clamp terminal connections are supported. MIL connectors are not applicable.
Q6: What are the isolation voltage ratings?
A6: 2 kV AC between input and system, and 500 V AC between channel commons (per 16-channel group).
Q7: What is the module’s current consumption?
A7: The maximum current consumption is 350 mA at 5 V DC.
Q8: What are the dimensions and weight of the ADV157 module?
A8: The module measures 130.9 × 130 × 32.8 mm and weighs 0.4 kg.
