Technical Specifications
| Item | Specification |
|---|---|
| Model | ALR111 |
| Interface | RS-232C |
| Connection Method | Point-to-point |
| Communication Function | Half-duplex |
| Synchronization Method | Start-stop synchronization |
| Transmission Speed | 1200 / 2400 / 4800 / 9600 / 19200 / 38400 bps |
| Transmission Code | ASCII / Binary |
| Character Length | 7 / 8 bits |
| Stop Bit Length | 1 / 2 bits |
| Parity Check | None / Even / Odd |
| Lag Time After Transmission | 1 ms |
| Maximum Transmission Distance | 15 m |
| Installation Method | Mounted on ANB10□, ANB11□, ANR10□, AFF50□, AFV10□, AFV30□, or AFV40□ |
| I/O Wiring | AKB131, AKB132, AKB133, AKB134 cables |
| Wiring Connection | D-sub 9-pin (female x2) |
| Current Consumption | 0.5 A |
| Dimensions | 126.7 × 32.8 × 130 mm |
| Weight | 0.3 kg |
FAQ
FAQ
Q1: What interface standard does ALR111 support?
A1: ALR111 supports the RS-232C standard interface.
Q2: What is the maximum communication distance of ALR111?
A2: The maximum communication distance is 15 meters.
Q3: What synchronization method does ALR111 use?
A3: It uses start-stop synchronization.
Q4: What is the transmission speed range of ALR111?
A4: Supported transmission speeds range from 1200 to 38400 bps.
Q5: What communication mode does ALR111 operate in?
A5: It operates in half-duplex mode.
Q6: What is the power consumption of ALR111?
A6: The operating current is 0.5A.
Q7: On which units can ALR111 be installed?
A7: It can be installed on ANB10□, ANB11□, ANR10□, AFF50□, AFV10□, AFV30□, and AFV40□.
Q8: What are the dimensions and weight of ALR111?
A8: Its dimensions are 126.7 × 32.8 × 130 mm, and it weighs 0.3 kg.
