Technical Specifications
| Parameter | Specification |
|---|---|
| Model | AMM32-S3 |
| Type | RTS Input Multiplexer Module |
| Input Signal | RTS (JIS JPt100 / Pt100, 3-wire) |
| Input Range | -200 to 600 °C |
| Input Resistance | 1 MΩ |
| Accuracy | ±0.15 Ω |
| Disconnection Detection Current | 0.1 µA |
| Signal Insulation | Isolated between systems |
| Data Update Period | 1 second |
| Power Supply | 5.0 V DC |
| Current Consumption | 500 mA or less |
| Installation | Installed in I/O Module Nest |
| Wiring Method | M4 screw terminals |
| Configuration | Input signal and range set via software |
| Dimensions (W x D x H) | 125 x 130 x 248 mm |
| Weight | 2 kg |
FAQ
FAQ
Q1: What is the main function of the Yokogawa AMM32-S3 module?
A1: The AMM32-S3 is an RTS input multiplexer module used to collect temperature signals from up to 16 resistance temperature sensors (RTDs) such as Pt100 and JPt100.
Q2: How many input channels does the AMM32-S3 support?
A2: It supports a maximum of 16 channels for RTS input, enabling simultaneous multi-point temperature monitoring.
Q3: How is the input signal configuration performed for this module?
A3: Input signal type and range are configured using software within the Yokogawa system.
Q4: Does the AMM32-S3 provide signal isolation?
A4: Yes, input signals are electrically isolated from the internal system to enhance safety and noise immunity.
Q5: Can the module be used with long-distance wiring?
A5: Yes, but the wiring resistance per wire should not exceed 150 Ω to maintain signal accuracy.
Q6: What is the accuracy of the AMM32-S3?
A6: The module provides an accuracy of ±0.15 Ω for RTS signals and compensates for ambient temperature variations.
Q7: How frequently does the AMM32-S3 update its measurements?
A7: It updates data every 1 second, providing timely input readings for the system.
Q8: What are the installation requirements for the AMM32-S3 module?
A8: The module must be installed in a designated I/O module nest, such as the AMN31 or AMN32, and connected using M4 screw terminals.
