Technical Specifications
| Parameter | Specification |
|---|---|
| Model | AMM32C |
| Type | Digital Input Multiplexer Module |
| Input Type | RTS (Resistance Temperature Detector) |
| Supported RTD Types | JIS JPt100 / JIS Pt100 (DIN Pt100), 3-wire |
| Input Range | -200 to 600 °C |
| Accuracy | ±0.15 Ω |
| Input Resistance | — |
| Signal Insulation | Isolated between systems |
| Disconnection Detection | Yes (Detection current: 0.1 µA) |
| Max. Common Mode Voltage | 200 V AC |
| RJC Input Range | -10 to 70 °C |
| RJC Accuracy | ±1 °C |
| Measuring Current | 1 mA |
| Allowable Wiring Resistance | Max. 150 Ω per wire |
| Update Period | 1 s |
| Burnout Detection | Selectable (UP / DOWN / OFF) |
| Installation | Installed in I/O Module Nest |
| Connection Method | Terminal block with M4 screws |
| Input Configuration | Set via software |
| Power Consumption | ≤ 500 mA (5.0 V DC) |
| Dimensions (W x D x H) | 125 x 130 x 248 mm |
| Weight | 2 kg |
FAQ
FAQ
Q1: What types of RTD sensors are supported?
A1: JIS JPt100 and JIS Pt100 (DIN Pt100) 3-wire RTDs are supported.
Q2: What is the input temperature range of the module?
A2: The input range is from -200 to 600 °C.
Q3: Does the module support disconnection detection?
A3: Yes, it includes disconnection detection with a detection current of 0.1 µA.
Q4: In which I/O nest should the module be installed?
A4: It must be installed in the AMN31 I/O module nest (Connector type).
Q5: What is the power consumption of the module?
A5: The maximum power consumption is 500 mA at 5.0 V DC.
Q6: Is input signal isolation provided?
A6: Yes, the input signals are isolated from the system with a withstand voltage of 1500 V AC/min.
Q7: How is the input signal type and range configured?
A7: The input type and range are configured through software.
Q8: How should the wiring be connected?
A8: Use M4 screws to connect the wiring to the terminal block of the I/O module nest.
