Technical Specifications
| Item | Specification |
|---|---|
| Model | AMM32TJ |
| Module Function | RTD Input Multiplexer Module |
| Input Type | RTD (Compliant with IEC751-1995) |
| Supported Sensors | JIS JPt100 or JIS Pt100 (DIN Pt100), 3-wire |
| Input Range | -200 to 600 °C |
| Measuring Current | 1 mA |
| Accuracy | ±0.15 Ω |
| Disconnection Detect | Up to 20 seconds |
| Detection Current | 0.1 μA |
| Signal Isolation | Isolated from system; Withstand Voltage: 1500 V AC/min |
| Allowed Wiring Resistance | Max. 150 Ω per wire |
| Installation | Mounted in I/O Module Nest |
| Wiring | Connected with M4 screws to module terminals |
| Data Update Period | 1 second |
| Parallel Input | Not permitted |
| Input Configuration | Defined via software |
| Power Consumption | Max. 500 mA (5.0 V DC) |
| Dimensions | 125 x 130 x 248 mm |
| Weight | 2 kg |
FAQ
Frequently Asked Questions (FAQ)
Q1: What types of RTD sensors does the AMM32TJ support?
A1: It supports 3-wire RTDs of JIS JPt100 and JIS Pt100 (DIN Pt100) standards.
Q2: Is signal isolation provided in the AMM32TJ module?
A2: Yes, all input signals are isolated from the system with a dielectric strength of 1500 V AC/min.
Q3: How many input points can the AMM32TJ handle?
A3: The module supports up to 16 input points.
Q4: How is the module installed?
A4: The AMM32TJ must be mounted in an I/O module nest and connected using M4 screws.
Q5: Can the input signal type be configured via software?
A5: Yes, both the input type and range are configurable through system software.
Q6: Is parallel input connection allowed?
A6: No, input channels must be used independently.
Q7: What is the data update cycle of this module?
A7: The data update cycle is 1 second.
Q8: Does the module support disconnection detection?
A8: Yes, it supports disconnection detection with a max delay of 20 seconds and 0.1 μA detection current.
