Technical Specifications
| Parameter | Specification |
|---|---|
| Model | AMM42T |
| Input Signal | 4 to 20 mA DC |
| Input Resistance | 250 Ω (can be changed to 70 Ω with barrier) |
| Transmitter Power Supply | 23.5 to 24.5 V DC (output power limit: 60 mA or less) |
| Output Signal | – |
| Output Resistance | 500 kΩ or more |
| Allowable Load Resistance | 0 to 750 Ω |
| Output Range | 1.0 to 21.5 mA DC |
| Output Voltage Limit | 25.5 V DC or less |
| Signal Insulation | Non-insulation between system-field, and channels |
| Data Update Period | 1 second |
| Accuracy Rating | ±16 µA |
| Current Consumption | 4 A or less (5.0 V DC) |
| Effect of Ambient Temperature Change | 10 °C of change: ±32 µA |
| Dimensions | 45 × 97 × 103 mm |
| Weight | 0.3 kg |
FAQ
FAQ
Q1: What is the input signal type for the AMM42T module?
A1: The AMM42T module accepts a 4 to 20 mA DC input signal.
Q2: Can the input resistance of the AMM42T module be modified?
A2: Yes, the input resistance is typically 250 Ω but can be changed to 70 Ω when connected to a barrier.
Q3: What is the power supply requirement for the AMM42T module?
A3: The transmitter power supply for the AMM42T is 23.5 to 24.5 V DC with a power limit of 60 mA or less.
Q4: Is there any output signal on the AMM42T module?
A4: No, the AMM42T module does not output a signal.
Q5: What is the accuracy rating of the AMM42T module?
A5: The accuracy rating of the AMM42T module is ±16 µA.
Q6: How often does the AMM42T module update its data?
A6: The AMM42T module updates data every 1 second.
Q7: What is the weight of the AMM42T module?
A7: The AMM42T module weighs 0.3 kg.
Q8: Can I use the AMM42T module in a hazardous area?
A8: No, the AMM42T module is not designed for use in hazardous areas. It does not comply with CSA standards for installation in those environments.
