Technical Specifications (AMM42-S4)
| Item | Specification |
|---|---|
| Model | AMM42-S4 |
| Input Signal Type | 4 to 20 mA DC (from 2-wire transmitters) |
| Channels | Up to 16 points |
| Input Resistance | 250 Ω (configurable to 70 Ω for barrier use) |
| Power Supply | 5.0 V DC supplied from I/O module nest |
| Transmitter Power | 23.5–24.5 V DC, max 60 mA |
| Data Update Period | 1 second |
| Accuracy | ±16 µA |
| Isolation | No isolation between system and field/channels |
| Current Consumption | Max 4 A (5.0 V DC) |
| Installation | Mounted in I/O module nest |
| Wiring | Connected via M4 screws to I/O module nest |
| Temp Effect | ±32 µA per 10°C change |
| Dimensions | 120 × 90 × 60 mm |
| Weight | 0.249 kg |
FAQ
Frequently Asked Questions (FAQ)
Q1: Does the AMM42-S4 support 2-wire transmitters?
A1: Yes, it is designed to receive 4–20 mA DC signals from 2-wire transmitters and provides power for them.
Q2: Is there isolation between channels or between system and field?
A2: No, AMM42-S4 does not provide electrical isolation between channels or between the system and field.
Q3: How many input channels does the module support?
A3: The module supports up to 16 input channels.
Q4: Can the module be used with safety barriers?
A4: Yes, by configuring the input resistance to 70 Ω, it can be used with MTL barriers like model 787S.
Q5: Are there installation precautions?
A5: The module must be installed in a dedicated I/O module nest and connected using M4 screws to ensure secure wiring.
Q6: What is the power consumption of this module?
A6: The module consumes up to 4 A at 5.0 V DC.
Q7: Does it have temperature compensation?
A7: No, it does not include temperature compensation, but has a deviation of ±32 µA per 10°C temperature change.
Q8: What are the dimensions and weight of the module?
A8: The module measures 120 × 90 × 60 mm and weighs 0.249 kg.
