Technical Specifications
| Parameter | Specification |
|---|---|
| Model | ANB10D-400 |
| Type | Dual-redundant ESB Bus Node Unit |
| Communication Protocol | ESB Bus |
| Power Supply | Supports I/O module power supply |
| Redundancy | Dual-redundant configuration for high availability |
| Node Capacity | Up to 8 nodes per FCU depending on license |
| Physical Dimensions | 482.6 × 221.5 × 205 mm |
| Weight | 10 kg |
| Operating Temperature | -20°C to +60°C |
| Storage Temperature | -30°C to +80°C |
| Humidity Tolerance | Up to 95% non-condensing |
| Mounting | Rack-mounted configuration |
FAQ
FAQ
-
What is the maximum number of ANB10D-400 units supported per FCU?
Up to 8 units can be connected per FCU depending on the software license and system configuration. -
Can the ANB10D-400 supply power to I/O modules?
Yes, it provides power to connected I/O modules, reducing the need for external power sources. -
What type of communication does the ANB10D-400 use?
It uses the ESB Bus communication protocol for high-speed and reliable data exchange. -
Is the ANB10D-400 suitable for redundant system configurations?
Yes, it supports dual-redundant configurations for enhanced system reliability. -
What is the operating temperature range for the ANB10D-400?
The unit can operate within -20°C to +60°C. -
How is the ANB10D-400 mounted in the system?
It is designed for rack-mounted installation to integrate with standard control system racks. -
What is the physical size of the ANB10D-400?
The dimensions are 482.6 × 221.5 × 205 mm. -
What is the weight of the ANB10D-400 unit?
The unit weighs 10 kg, making it manageable for standard rack installations.
