Technical Specifications
| Parameter | Description |
|---|---|
| Model | ANB10D-410/CU2N |
| Type | ESB Bus Node Unit (for N-IO/FIO) |
| Dimensions | 482.6 × 221.5 × 205 mm |
| Weight | 10 kg |
| Power Input | 100–120 V AC, 220–240 V AC, 24 V DC |
| Power Consumption | 100–120 V AC: 200 VA / 120 W; 220–240 V AC: 230 VA / 120 W; 24 V DC: 5.5 A |
| Mounting | 19-inch rack mountable |
| I/O Module Support | Up to 8 I/O modules |
| ESB Bus Interface | Supports dual-redundant configuration; requires ESB bus coupler module (EC401 or EC402) |
| Environmental Conditions | Operating Temperature: -20°C to +60°C; Storage Temperature: -30°C to +80°C; Humidity: Up to 95% RH (non-condensing) |
| Protection Rating | IP20 (for indoor use only) |
| Connector Unit | Includes CU2N connector unit (Part No.: S9562FA) |
| Node Expansion License | Requires /NDEL option code to connect additional node units |
FAQ
FAQ
Q1: What is the maximum number of I/O modules supported by the ANB10D-410/CU2N?
A1: The unit supports up to 8 I/O modules.
Q2: How do I configure dual-redundant power for the ANB10D-410/CU2N?
A2: Dual-redundant power modules are required, and two independent power inputs must be provided.
Q3: What power input options are supported by the ANB10D-410/CU2N?
A3: The unit supports 100–120 V AC, 220–240 V AC, and 24 V DC power input options.
Q4: How do I connect the ANB10D-410/CU2N to a Field Control Unit (FCU)?
A4: Install an ESB bus coupler module (EC401 or EC402) into the FCU and connect via the ESB bus.
Q5: What is the operating temperature range of the ANB10D-410/CU2N?
A5: The operating temperature range is -20°C to +60°C.
Q6: What is the storage temperature range of the ANB10D-410/CU2N?
A6: The storage temperature range is -30°C to +80°C.
Q7: What is the protection rating of the ANB10D-410/CU2N?
A7: The protection rating is IP20, suitable for indoor use only.
Q8: How do I expand the number of nodes for the ANB10D-410/CU2N?
A8: The /NDEL option code is required to obtain a node expansion license, allowing connection of additional node units.
