Technical Specifications
| Parameter | Specification |
|---|---|
| Model | ANB10D-425/CU2T |
| Bus Type | Dual-redundant ESB Bus |
| Power Supply Voltage Options | 100–120 V AC / 220–240 V AC / 24 V DC |
| Power Supply Frequency | 50/60 Hz |
| Power Consumption | 120 W (100–120 V AC: 200 VA, 220–240 V AC: 230 VA) |
| DC Current Consumption | 5.5 A (24 V DC) |
| Mounting | 19-inch rack mounting (M5 x 4 screws) |
| I/O Module Capacity | Up to 8 modules |
| Communication Interface Module | Dual SB401 modules (for redundancy) |
| Power Supply Module | Dual PW481 / PW482 / PW484 (for redundancy) |
| Dimensions (W × H × D) | 482.6 × 221.5 × 205 mm |
| Weight | Approx. 10 kg (including 8 I/O modules) |
| Connector Unit | /CU2T (with Terminator, Part No.: S9564FA × 2) |
| Installation Configuration | Up to 11 node units per cabinet (with AFV40 systems) |
FAQ
FAQ
Q1: What is the function of the ANB10D-425/CU2T unit?
A1: It interfaces field analog and contact I/O signals with the Field Control Unit (FCU) and supplies power to the I/O modules.
Q2: What is the maximum number of I/O modules supported?
A2: The unit supports up to 8 I/O modules.
Q3: What type of bus configuration does this model use?
A3: It uses a dual-redundant ESB Bus configuration for enhanced reliability.
Q4: Is the unit compatible with 24 V DC power supply?
A4: Yes, the unit can be operated with 24 V DC, requiring 5.5 A.
Q5: What kind of mounting method is required?
A5: It is designed for 19-inch rack mounting using M5 x 4 screws.
Q6: What is included in the /CU2T option?
A6: The /CU2T option includes two ESB Bus connector units with terminators (Part No. S9564FA).
Q7: Can this unit be used in a cabinet with high ambient temperatures?
A7: Yes, if configured with G3 option and -20°C to +70°C temperature support.
Q8: What redundancy features are available?
A8: It supports dual-redundant power supply and dual ESB Bus interface modules.
