Technical Specifications
| Parameter | Specification |
|---|---|
| Model | ANR10D-420 |
| Product Type | ER Bus Node Unit |
| Bus Type | ER Bus (10 Mbps, coaxial cable YCB141/YCB311) |
| Communication Topology | Bus topology |
| Transmission Redundancy | Dual-redundant or single (dual-redundant mandatory with dual CPU) |
| Max. ER Bus Node Units | Up to 14 per FCU (when LFS1550 expansion is used) |
| Max. ER Buses per FCU | 4 |
| Max. Distance (YCB141 cable) | 185 m |
| Max. Distance (YCB311 + YCB141) | Combined length must satisfy: L(YCB141) + (185/500)×L(YCB311) ≤ 185 m |
| Transmission Speed | 10 Mbps |
| Cable Type | Coaxial (YCB141, YCB311 via adapters) |
| Connectors | BNC |
| Power Supply | Supplied via connected system (rack-mounted) |
| Dimensions (W×H×D) | 482.6 × 221.5 × 205 mm |
| Weight | 10 kg |
FAQ
Frequently Asked Questions (FAQ)
Q1: What is the primary function of the ANR10D-420 unit?
A1: It functions as a node on the ER bus for input/output communication between the control station and field devices.
Q2: How many ANR10D-420 units can be connected to one ER bus?
A2: A maximum of 8 units can be connected per ER bus segment.
Q3: Can the ANR10D-420 be used in a dual-redundant configuration?
A3: Yes, dual-redundant communication is supported and mandatory if the control processor is redundant.
Q4: What cable types are compatible with this unit?
A4: It supports YCB141 coaxial cable and YCB311 (with adapter) for extended connections.
Q5: Is optical fiber supported for ANR10D-420?
A5: No, the ER bus uses only coaxial cables; optical fiber is not applicable.
Q6: What is the recommended maximum distance for communication?
A6: 185 meters using YCB141, or a mixed cable setup within equivalent distance limitations.
Q7: What environmental conditions are required for installation?
A7: Operating temperature 0–50°C, humidity 10–90% RH (non-condensing).
Q8: What is the transmission speed of the ANR10D-420?
A8: The unit operates at a fixed transmission speed of 10 Mbps.
