Technical Specifications
| Item | Specification |
|---|---|
| Model | ANB11D-425/BU2A |
| Type | Dual-redundant ESB Bus Node Unit with Optical Repeater |
| Communication | Optical ESB Bus |
| Bus Topology | Supports chain and star connections |
| Max Transmission Distance | Up to 4 km per hop |
| Max Hops | Up to 2 hops; each FCU supports up to 8 hops |
| Optical Connector Type | LC type |
| Power Supply | Dual-redundant; supports 100–120V AC, 220–240V AC, 24V DC input |
| Environmental Monitoring Interface | Optional HKU interface for cabinet temperature and fan monitoring |
| Mounting Type | Rack-mountable |
| Dimensions (W x H x D) | 482.6 × 221.5 × 205 mm |
| Weight | 10 kg |
| Operating Temperature Range | -20°C to +70°C |
| Explosion Protection | Depends on model; standard type without explosion protection; some models support explosion protection |
| Compatible Modules | Compatible with ANT421, ANT522 optical ESB bus repeater modules |
| Connection Method | Connects to FCU via EC401 or EC402 modules |
FAQ
FAQ
Q1: What power input types are supported by the node unit?
A1: The node unit supports 100–120V AC, 220–240V AC, and 24V DC inputs, all in dual-redundant configuration for high system reliability.
Q2: What is the maximum transmission distance of the node unit?
A2: With ANT421 and ANT522 optical ESB bus repeater modules, the maximum transmission distance per hop is up to 4 km.
Q3: What bus topologies are supported by the node unit?
A3: Supports both chain and star topologies to accommodate different system designs.
Q4: What is the operating temperature range of the node unit?
A4: The operating temperature range is -20°C to +70°C, suitable for diverse industrial environments.
Q5: Does the node unit support environmental monitoring?
A5: Optional HKU interface is available for monitoring cabinet temperature and fan status, requiring a separate order.
Q6: What are the dimensions and weight of the node unit?
A6: Dimensions are 482.6 × 221.5 × 205 mm, weight is 10 kg, suitable for 19-inch rack mounting.
Q7: What type of optical connectors does the node unit use?
A7: LC-type optical connectors are used, ensuring stable and reliable fiber connections.
Q8: Does the node unit have explosion protection?
A8: Explosion protection depends on the model; standard type does not have it, while some models support explosion protection.
