Technical Specifications
| Parameter | Specification |
|---|---|
| Model Number | ASI533-S00 S1 |
| Output Channels | 8 channels, individually isolated |
| Output Signal Type | Current (4–20 mA), Voltage (0–10 V) |
| Resolution | 16-bit high precision |
| Output Load Resistance | Current mode: 0–750 Ω Voltage mode: 0–10 V |
| Accuracy | ±0.1% full scale |
| Update Speed | 10 ms per channel |
| Power Supply | 24 V DC |
| Power Consumption | Approx. 6 W |
| Operating Temperature | -10°C to +60°C |
| Storage Temperature | -20°C to +85°C |
| Dimensions | 107.5 × 130 × 32.8 mm |
| Weight | 0.3 kg |
FAQ
FAQ
-
What type of analog signals does the ASI533-S00 S1 support?
The module supports both current (4–20 mA) and voltage (0–10 V) output signals suitable for industrial control devices. -
How fast can the module update its output channels?
Each channel updates at 10 milliseconds, enabling real-time response for process control. -
What is the precision level of the output signals?
The module provides 16-bit resolution with ±0.1% full-scale accuracy. -
Can this module operate in harsh industrial environments?
Yes, it supports an operating temperature range of -10°C to +60°C and storage up to +85°C. -
How are the output channels isolated?
Each of the 8 channels is individually isolated to prevent interference between signals. -
What is the maximum load resistance for current output?
The current output can drive up to 750 Ω without compromising signal accuracy. -
Is this module compatible with distributed control systems?
Yes, it is designed to integrate seamlessly with DCS systems like Yokogawa CENTUM VP. -
What are the module’s physical dimensions and weight?
The module measures 107.5 × 130 × 32.8 mm and weighs approximately 0.3 kg.
