Technical Specifications
| Parameter | Specification |
|---|---|
| Model | SAI143-S63/A4S00 |
| Input Type | 16 isolated channels |
| Signal Range | 4 to 20 mA per channel |
| Permissible Input Range | 0 to 25 mA |
| Input Impedance | Power-On: 250 Ω + current value Power-Off: ≥500 kΩ |
| Accuracy | ±16 µA (input range 1–23 mA) |
| Data Update Frequency | 40 ms |
| Temperature Drift | ±16 µA/10°C |
| Transmitter Power Supply | 16.15 V minimum at 20 mA |
| Mounting Compatibility | Field Control Units or Safety Node Units |
| Redundancy | Supports dual-redundant configurations |
| Connection Types | Pressure clamp terminal, MIL connector cable, KS1 cable |
| Operating Temperature Range | -20 to 70°C |
| Explosion Protection | None specified |
| Dimensions | 130 × 107.5 × 32.8 mm |
| Weight | 0.39 kg |
FAQ
FAQ
-
Q1: What is the maximum number of analog inputs that SAI143-S63/A4S00 can handle?
A1: The module supports up to 16 isolated analog input channels. -
Q2: What is the permissible input current range for each channel?
A2: Each channel can accept a current range of 0 to 25 mA, with a nominal operating range of 4–20 mA. -
Q3: How precise is the SAI143-S63/A4S00 in measuring current signals?
A3: The accuracy is ±16 µA for input currents between 1 and 23 mA. -
Q4: Can this module be used in redundant safety configurations?
A4: Yes, the module supports dual-redundant configurations for safety-critical applications. -
Q5: What is the response time for signal update?
A5: The module updates input data every 40 milliseconds. -
Q6: What are the operating temperature limitations for this analog input module?
A6: It operates reliably within a temperature range of -20°C to 70°C. -
Q7: How is the module powered for transmitter signals?
A7: It provides a transmitter power supply of at least 16.15 V at 20 mA. -
Q8: What types of connection interfaces are available for field wiring?
A8: Connections are available via pressure clamp terminals, MIL connector cables, or KS1 dedicated cables.
