Technical Specifications
| Parameter | Specification |
|---|---|
| Input Channels | 16 isolated channels |
| Input Signal | 4 to 20 mA |
| Permissible Input Range | 0 to 25 mA |
| Input Impedance (Power-ON) | 250 Ω + current value |
| Input Impedance (Power-OFF) | 500 kΩ minimum |
| Rated Accuracy | ±16 µA (for input range 1 to 23 mA) |
| Data Update Frequency | 40 ms |
| Temperature Drift | ±16 µA/10 °C |
| Transmitter Power Supply | 16.15 V minimum (at 20 mA), 26.4 V maximum (at 0 mA) |
| Isolation | Module isolation between input and system |
| Withstand Voltage | 1.5 kV AC between input signal and system for 1 minute |
| Maximum Current Consumption | 320 mA (5 V system), 550 mA (24 V system) |
| Temperature Range | -20°C to 70°C |
| Connection Types | Pressure clamp terminal, MIL connector cable, or dedicated cable (KS1) |
| Redundancy | Dual-redundant communication supported |
| Dimensions | 130 x 107.5 x 32.8 mm |
| Weight | 0.39 kg |
| Explosion Protection | None |
| Signal Cable Interface Adapter | Included |
| ISA Standard G3 Compliance | Yes |
| HART Communication | Optional depending on configuration |
FAQ
FAQ
-
Q1: What types of input signals can the SAI143-S63 module handle?
A1: It handles 4 to 20 mA current signals and supports up to 25 mA as permissible input. -
Q2: How accurate is the SAI143-S63 in measuring analog inputs?
A2: The module provides ±16 µA accuracy within the 1 to 23 mA input range. -
Q3: What is the data update rate of this module?
A3: The data update frequency is 40 milliseconds. -
Q4: Can this module operate in high-temperature environments?
A4: Yes, it supports a temperature range from -20°C to 70°C. -
Q5: Does the module provide electrical isolation?
A5: Yes, each input channel is isolated from the system to ensure signal integrity. -
Q6: What are the physical dimensions and weight of the module?
A6: Dimensions are 130 x 107.5 x 32.8 mm, and it weighs 0.39 kg. -
Q7: Can the SAI143-S63 module support redundant communication?
A7: Yes, dual-redundant communication is supported by installing two communication modules on the same unit. -
Q8: What connection options are available for field wiring?
A8: It supports pressure clamp terminals, MIL connector cables, or dedicated KS1 cables.
