Technical Specifications
| Parameter | Description |
|---|---|
| Model Number | SCP401-11 |
| Product Type | Processor Module (for ProSafe-RS SCS) |
| Applicable Systems | Yokogawa ProSafe-RS SSC10S / SSC10D |
| Processor Configuration | Single or Redundant |
| Application Environment | Safety Instrumented System (SIS) |
| Input Power | Supplied via backplane from SPW48x module |
| Communication Interface | ESB Bus (via SEC401 module) |
| LED Indicators | DX, ACT, STATUS |
| Installation | Mounted in processor slot of SCS base unit |
| Operating Temperature | -20°C to +50°C (Standard Type) |
| Storage Temperature | -40°C to +70°C |
| Relative Humidity | 5% to 95% (non-condensing) |
| Conformal Coating | Yes |
| EMC Compliance | IEC 61000-6-2, EN 55011 Class A, etc. |
| Functional Safety Standard | IEC 61508 (SIL 3 Certified) |
| Mounting | Rack-mounted (base unit slot) |
| Dimensions (W x H x D) | 200 x 90 x 155 mm |
| Weight | 0.85 kg |
FAQ
FAQ
Q1: What is the main function of the SCP401-11 module?
A1: The SCP401-11 is a processor module used in Yokogawa’s ProSafe-RS SCS to execute safety logic and manage system communication.
Q2: Which systems is the SCP401-11 compatible with?
A2: It is designed for use in ProSafe-RS systems, specifically with SSC10S and SSC10D safety control units.
Q3: Does the module support redundancy?
A3: Yes, the SCP401-11 can be used in either single or dual-redundant configurations for increased system reliability.
Q4: Does the module require a separate power supply?
A4: No, it receives power from the backplane via SPW48x series power supply modules.
Q5: Where should the SCP401-11 be installed?
A5: It must be installed in the processor slot of the SCS base unit and securely grounded.
Q6: Is the module safety certified?
A6: Yes, it is certified to IEC 61508 and supports SIL 3 functional safety.
Q7: Are there any diagnostic indicators on the module?
A7: Yes, it features DX, ACT, and STATUS LEDs on the front panel for status monitoring and troubleshooting.
Q8: Can it operate in harsh industrial environments?
A8: Yes, it operates in temperatures from -20°C to +50°C and is protected by a conformal coating, suitable for demanding conditions.
