Technical Specifications
| Parameter | Description |
|---|---|
| Product Model | Allen-Bradley 1336-BR-SP5A |
| Manufacturer | Allen-Bradley (Rockwell Automation) |
| Product Series | 1336 Drive Series Spare Parts |
| Product Type | SCR Bridge Rectifier Assembly |
| Function | Converts incoming AC power to DC bus power for Allen-Bradley 1336 series variable frequency drives |
| Application | Variable frequency drives, AC motor control systems, industrial automation equipment |
| Compatible Drives | Allen-Bradley 1336 STE Series A-D, 1336 FORCE Series A, 230V drive systems |
| Rectifier Type | SCR Bridge Rectifier |
| Voltage Class | 230 VAC |
| Component Function | Input power rectification and DC bus charging |
| Mounting Type | Internal drive power section mounting |
| Installation Location | Inside Allen-Bradley 1336 drive power module assembly |
| Semiconductor Type | SCR (Silicon Controlled Rectifier) bridge |
| Control Function | Controlled rectification for drive DC link power conversion |
| Replacement Application | Spare replacement component for 1336 series drives |
| Lifecycle Status | Obsolete / replaced by newer spare part version |
| Dimensions | Approx. 150 × 100 × 60 mm |
| Weight | Approx. 0.8 kg |
FAQ
FAQ
Q1: What is the Allen-Bradley 1336-BR-SP5A used for?
A: The 1336-BR-SP5A is an SCR bridge rectifier assembly used in Allen-Bradley 1336 drives to convert AC input power into DC bus power required by the drive inverter section.
Q2: Which Allen-Bradley drives are compatible with the 1336-BR-SP5A?
A: It is designed for 230V Allen-Bradley 1336 STE Series A-D and 1336 FORCE Series A drives.
Q3: Is the 1336-BR-SP5A a complete variable frequency drive?
A: No. It is only a replacement power component installed inside compatible 1336 drive assemblies.
Q4: What is the main function of the SCR bridge rectifier?
A: The SCR bridge rectifier controls the conversion of incoming AC power into DC voltage, supplying the drive’s DC bus for motor control operation.
Q5: Is the 1336-BR-SP5A still available from Rockwell Automation?
A: The 1336-BR-SP5A is listed as an obsolete spare part and has been replaced by a newer spare part version, such as 1336-BR-SP6A.
Q6: What are the dimensions and weight of the 1336-BR-SP5A?
A: The approximate dimensions are 150 × 100 × 60 mm, and the weight is approximately 0.8 kg. Actual values may vary depending on hardware revision and packaging.
Q7: Can the 1336-BR-SP5A replace other rectifier assemblies?
A: Replacement should only be performed after confirming the drive model, voltage rating, SCR configuration, mounting style, and original part number.
Q8: What should be checked before installing the 1336-BR-SP5A?
A: Verify the drive voltage rating, inspect power connections, confirm the replacement part number, discharge the DC bus voltage, and follow proper electrical safety procedures before installation.
