Technical Specifications
| Parameter | Description |
|---|---|
| Product Model | Allen-Bradley 1336F-MCB-SP1G |
| Manufacturer | Allen-Bradley (Rockwell Automation) |
| Product Series | 1336 PLUS II Drive Series |
| Product Type | Main Control PC Board / Drive Control Board |
| Function | Provides the main control logic, drive regulation, communication management, and input/output processing for 1336F series variable frequency drives |
| Application | AC motor control, industrial automation systems, variable frequency drive maintenance and replacement |
| Compatible Drive Series | Allen-Bradley 1336 PLUS II Drives |
| Supported Drive Frames | Frame B through G |
| Control Voltage | 230–460 VAC |
| Input Control Power | 115 VAC |
| Operating Frequency | 50/60 Hz |
| Communication Interface | SERCOS interface, ControlLogix compatible interface |
| Analog Input Range | 0–20 mA, 0–10 VDC, 0–10 kΩ |
| Analog Output Range | 0–20 mA, 0–10 VDC |
| Relay Contact Rating | 240 VAC, 2 A |
| Programmable Outputs | CR1, CR2, CR3 |
| Board Function | Motor control processing, drive parameter management, feedback processing, and communication control |
| Installation Type | Internal replacement PCB installed inside 1336F drive chassis |
| Mounting Method | Drive internal mounting bracket |
| Construction | Industrial-grade printed circuit board assembly |
| Replacement Part Number | 1336F-MCB-SP1G |
| Lifecycle Status | Discontinued / legacy spare part |
| Dimensions | Approx. 216 × 76 × 25 mm |
| Weight | Approx. 0.45 kg |
FAQ
FAQ
Q1: What is the Allen-Bradley 1336F-MCB-SP1G used for?
A: The 1336F-MCB-SP1G is the main control board for Allen-Bradley 1336 PLUS II drives. It controls drive operation, processes feedback signals, manages parameters, and handles communication functions.
Q2: Which drives are compatible with the 1336F-MCB-SP1G?
A: It is designed for Allen-Bradley 1336 PLUS II drive systems and supports drive frames from B through G.
Q3: What communication interfaces are supported by this control board?
A: The board supports SERCOS communication and ControlLogix-related interfaces for integration with industrial automation control systems.
Q4: Is the 1336F-MCB-SP1G a complete variable frequency drive?
A: No. It is only the main control PCB assembly and must be installed inside a compatible Allen-Bradley 1336F drive unit.
Q5: What input and output signals does the 1336F-MCB-SP1G support?
A: The board supports analog inputs and outputs including 0–20 mA and 0–10 VDC signals, along with programmable relay outputs for drive control applications.
Q6: What are the dimensions and weight of the 1336F-MCB-SP1G?
A: The approximate dimensions are 216 × 76 × 25 mm, and the weight is approximately 0.45 kg. Actual values may vary depending on hardware revision and packaging.
Q7: Can the 1336F-MCB-SP1G replace another 1336 control board?
A: Replacement is only recommended after confirming the complete part number, drive series, frame size, firmware compatibility, and board revision.
Q8: What should be checked before installing the 1336F-MCB-SP1G?
A: Verify the drive model, board revision, connectors, parameter backup, and wiring configuration. Disconnect power and discharge the DC bus before replacing the control board to ensure safe installation.
