Technical Specifications
| Parameter | Specification |
|---|---|
| Product Type | Industrial AC/DC Compact Switched‑Mode Power Supply |
| Product Family | Allen‑Bradley 1606‑XLP Compact Series |
| Part Number | 1606‑XLP100E |
| Input Voltage (AC) | Auto‑select: 100–120 V AC / 220–240 V AC, 50/60 Hz |
| Input Voltage (DC) | 220–375 V DC |
| Operational Input Range | 85–264 V AC or 220–375 V DC |
| Rated Input Current | < 2.1 A @ 100 V AC |
| Nominal Output Voltage | 24 V DC |
| Adjustable Output Voltage | 24–28 V DC |
| Rated Output Current | 4.2 A @ 24.5 V DC |
| Output Power | 100 W |
| Efficiency (typical) | ~90 % |
| Hold‑up Time | >40 ms @ 230 V AC |
| Ripple & Noise (max) | ≤ 50 mV (peak‑to‑peak) |
| Protection Features | Overload and short‑circuit protection |
| Signal Output | DC‑OK indicator |
| Connection Type | Spring clamp terminals |
| Mounting | 35 mm DIN‑rail & wall mount possible |
| Degree of Protection (IP) | IP20 |
| Operating Temperature Range | –10 °C to +70 °C |
| Storage Temperature Range | –40 °C to +85 °C |
| Relative Humidity | < 95 % non‑condensing |
| MTBF | ~500,000 h @ 40 °C, SN29500 |
| Dimensions (W × H × D) | 73 mm × 75 mm × 103 mm |
| Weight | ~360 g |
FAQ
FAQ
Q1: What type of product is the 1606‑XLP100E?
It is an industrial compact AC/DC switched‑mode power supply from the Allen‑Bradley 1606‑XLP series.
Q2: What input voltages does the 1606‑XLP100E support?
It auto‑selects between 100–120 V AC or 220–240 V AC and also supports DC input from 220 to 375 V.
Q3: What is the output voltage and current rating?
The supply delivers a regulated 24 V DC output, adjustable up to 28 V DC, with a rated current of 4.2 A.
Q4: How much output power can this model provide?
It provides up to 100 W of DC output power.
Q5: What are the physical dimensions and weight?
The unit measures 73 mm × 75 mm × 103 mm and weighs approximately 360 g.
Q6: What protections and features does the 1606‑XLP100E include?
It includes overload and short‑circuit protection and has a DC‑OK indicator to show output status.
Q7: What environmental conditions can this power supply operate in?
It operates from –10 °C up to +70 °C with IP20 protection and < 95 % non‑condensing humidity.
Q8: Can the 1606‑XLP100E be mounted on a DIN‑rail?
Yes, it supports DIN‑rail mounting and can also be wall mounted.
