Technical Specifications
| Specification | Parameter |
|---|---|
| Part Number / Model | 1761‑L10BXB |
| Module Type | MicroLogix 1000 Programmable Controller |
| System Compatibility | MicroLogix 1000 PLC series |
| Input Voltage | 24 V DC (20.4–26.4 V DC operational range) |
| I/O Configuration | 10 total I/O points (6 digital inputs; 4 outputs) |
| Digital Inputs | Six (6) 24 V DC discrete inputs |
| Outputs | Two (2) MOSFET sourcing 24 V DC outputs and two (2) relay outputs |
| Communication Interface | RS‑232 serial port (DF1 protocol) |
| Memory | 1 KB EEPROM (737 instruction words; 437 data words) |
| Power Consumption | ~5 W (@ 24 V DC) |
| Safety Feature | Master Control Relay included |
| Mounting | DIN rail or panel mount |
| Operating Temperature | 0–55 °C (32–131 °F) |
| Storage Temperature | –40–85 °C |
| Humidity (Operating) | 5–95 % non‑condensing |
| Enclosure Rating | IP20 ‑ controller housing required |
| Dimensions (L × W × H) | ~120 mm × ~40 mm × ~80 mm |
| Weight | ~0.28 kg (0.63 lbs) |
| Lifecycle Status | Discontinued (end of sale June 30, 2017) |
FAQ
FAQ
Q1: What is the 1761‑L10BXB designed for?
It is a small programmable controller for simple machine and process automation tasks.
Q2: How many inputs and outputs does it have?
It has six digital inputs and four outputs (two MOSFET sourcing and two relay outputs).
Q3: What power supply voltage does it require?
It operates on 24 V DC power (typically 20.4–26.4 V DC).
Q4: What communication interface is included?
It includes an RS‑232 serial port supporting the DF1 protocol for programming and data transfer.
Q5: How much memory does the controller have?
It has 1 KB of EEPROM memory for program and data storage.
Q6: Can this controller be mounted on a DIN rail?
Yes, it supports DIN rail or panel mounting.
Q7: What are the operating environmental limits?
Typical industrial operating temperature is 0–55 °C with 5–95 % non‑condensing humidity.
Q8: Is this product still current?
No, it has been discontinued and replaced by newer MicroLogix or CompactLogix series products.
