Technical Specifications
| Specification | Parameter |
|---|---|
| Part Number / Model | 1761‑L20BWA‑5A |
| Module Type | MicroLogix 1000 Programmable Controller |
| System Compatibility | MicroLogix 1000 PLC series |
| Power Supply | 120–240 V AC (85–264 VAC) |
| Input Signal Type | 24 V DC discrete inputs |
| I/O Count | 20 total I/O points (12 digital inputs; 8 outputs) |
| Digital Inputs | Twelve (12) 24 V DC inputs |
| Discrete Outputs | Eight (8) relay outputs |
| Output Type | Relay contacts (AC/DC switching) |
| Analog Inputs | Four (4) analog inputs (voltage/current) |
| Analog Input Range | ±10 V DC / ±20 mA (typical) |
| Analog Output | One (1) analog output (configurable 0–10 V DC / 4–20 mA) |
| Communication Interface | RS‑232 serial (DF1 protocol) |
| Memory | 1 KB EEPROM (program + data) |
| Master Control Relay | Yes (built‑in safety feature) |
| Operating Temperature | 0–55 °C typical |
| Humidity (Operating) | 5–95 % non‑condensing |
| Mounting | DIN rail or panel mount |
| Dimensions (L × W × H) | ~200 mm × ~73 mm × ~80 mm (approx) |
| Weight | ~0.26 kg (0.56 lb) |
| Lifecycle Status | Discontinued (end of sale Jun 30, 2017) |
FAQ
FAQ
Q1: What is the 1761‑L20BWA‑5A used for?
It is a compact PLC controller for small industrial automation tasks, integrating discrete and analog control.
Q2: How many I/O points does this controller have?
It has 20 I/O points: twelve digital 24 V DC inputs and eight relay outputs.
Q3: Does it support analog signals?
Yes — it includes four analog inputs and one configurable analog output.
Q4: What power supply does it require?
This controller runs on 120–240 V AC mains power.
Q5: What communication interface does it provide?
It has an RS‑232 serial port using the DF1 communication protocol.
Q6: How much memory does it have?
It includes 1 KB EEPROM memory for program and data storage.
Q7: What safety feature is built in?
It features a Master Control Relay for enhanced safety logic control.
Q8: Is the 1761‑L20BWA‑5A still current?
No — this model has been discontinued and is considered obsolete.
