Technical Specifications
| Specification | Parameter |
|---|---|
| Part Number / Model | 1761‑L32AAA |
| Module Type | MicroLogix 1000 Programmable Controller |
| System Compatibility | MicroLogix 1000 PLC series |
| Power Supply | 120–240 V AC mains |
| I/O Count | 32 total I/O points – 20 digital inputs, 12 outputs |
| Digital Inputs | Twenty (20) 120 V AC discrete inputs |
| Outputs | Ten (10) TRIAC outputs (AC) and Two (2) relay outputs |
| Output Type | TRIAC for AC loads; relay contacts for AC/DC loads |
| Communication Interface | RS‑232 serial port (DF1 protocol) |
| Memory Capacity | 1 KB EEPROM (approx. 737 instruction words; 437 data words) |
| Safety Feature | Master Control Relay (MCR) |
| Mounting | DIN rail or panel mount |
| Operating Temperature | 0 °C to 55 °C |
| Humidity (Operating) | 5–95 % non‑condensing |
| Dimensions (L × W × H) | ~200 mm × ~73 mm × ~80 mm (~7.87″ × ~2.87″ × ~3.15″) |
| Weight | ~0.88 kg (~1.94 lb) |
| Lifecycle Status | Discontinued/Obsolete (end of sale February 28, 2017) |
FAQ
FAQ
Q1: What is the 1761‑L32AAA used for?
It is a compact programmable logic controller used in small automation and control systems.
Q2: How many I/O points does it have?
It has 32 I/O points: 20 AC digital inputs and 12 outputs (10 TRIAC and 2 relay).
Q3: What power supply voltage does this controller require?
It operates on 120–240 V AC mains power.
Q4: What communication interface is included?
It features an RS‑232 serial port supporting the DF1 protocol for programming and communication.
Q5: What is the onboard memory capacity?
It includes 1 KB of EEPROM memory for program and data storage.
Q6: Does this controller include any safety feature?
Yes — it has a Master Control Relay for safety logic control.
Q7: What are the environmental operating limits?
Typical operating conditions are 0 °C to 55 °C with 5–95 % non‑condensing humidity.
Q8: Is the 1761‑L32AAA still in production?
No — it has been discontinued and is considered obsolete.
