Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Rockwell Automation / Allen-Bradley |
| Product Series | Stratix 5800 |
| Model Number | 1783-MMS10ER |
| Product Type | Managed Industrial Ethernet Switch |
| Switch Type | Modular Layer 3 Managed Switch |
| Firmware Type | Layer 3 Routing Firmware |
| Total Ports | 10 Ports |
| Copper Ports | 8 × 10/100/1000 Mbps PoE RJ45 Ports |
| Fiber Ports | 2 × Gigabit SFP Slots |
| PoE Standard | IEEE 802.3af / 802.3at PoE/PoE+ |
| Ethernet Speed | Gigabit Ethernet |
| Supported Protocols | EtherNet/IP, VLAN, STP, RSTP, MSTP, SNMP, DHCP, IGMP |
| Routing Features | Static Routing, OSPF, EIGRP, VRF-Lite |
| Operating System | Cisco IOS-XE |
| Precision Time Protocol | IEEE 1588 PTP |
| Network Security | ACL, Port Security, MACsec |
| Redundant Power Inputs | Yes |
| Input Voltage | 12…48V DC |
| Power Budget for PoE | Up to 360 W Shared |
| Mounting Type | DIN Rail Mount |
| Enclosure Rating | IP30 |
| Operating Temperature | -40°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Relative Humidity | 5% to 95% Non-Condensing |
| Certifications | UL, CE, KC, ATEX, IECEx, EtherNet/IP |
| Lifecycle Status | Active |
| Actual Dimensions (H × W × D) | Approx. 188 × 224 × 234 mm |
| Actual Weight | Approx. 3.5 kg |
| Typical Applications | Industrial Ethernet Networks, Factory Automation, High-availability Control Systems, Process Automation |
FAQ
FAQ
Q1: What is the Allen-Bradley 1783-MMS10ER used for?
A1: The 1783-MMS10ER is a Stratix 5800 managed industrial Ethernet switch designed for high-performance industrial networking and EtherNet/IP communications.
Q2: How many ports does the 1783-MMS10ER provide?
A2: The switch includes 8 Gigabit PoE copper ports and 2 Gigabit SFP fiber slots for a total of 10 ports.
Q3: Does the 1783-MMS10ER support Layer 3 routing?
A3: Yes. The switch includes Layer 3 routing firmware supporting functions such as static routing, OSPF, and EIGRP.
Q4: What operating system does the 1783-MMS10ER use?
A4: The switch uses Cisco IOS-XE, allowing enterprise-grade industrial network management and security integration.
Q5: What are the actual dimensions and weight of the 1783-MMS10ER?
A5: The approximate dimensions are 188 × 224 × 234 mm (H × W × D), and the approximate weight is 3.5 kg.
Q6: What power input does the 1783-MMS10ER require?
A6: The switch operates from redundant 12…48V DC power inputs.
Q7: Does the 1783-MMS10ER support PoE devices?
A7: Yes. All 8 copper ports support IEEE 802.3af/at PoE and PoE+ with a shared power budget up to 360 W.
Q8: What are common applications for the 1783-MMS10ER?
A8: Common applications include industrial automation networks, PLC communications, process control systems, manufacturing Ethernet backbones, and high-availability industrial networking.
